Home > Industrial Equipment & Components > Refrigeration Equipment > Cold Room > Freezer Room for Frozen Meat Chicken Fish
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Model Number:
ANE-004
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Jiangsu, China
Model Number
ANE-004
Certification
CE/SGS
Warranty
1-2 Years
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Range of application of cold storage for potato
-Vegetable, Fruit, Meat, Seafood, Medical, Agricultural, Chemical industry, Restaurant, etc.
Feature of cold storage for potato
(1) Temperature : 20ºC to - 45ºC( According to user requirements )
(2) Size: Customization.
(3) Functions: for the Meat /Fish /Vegetable fresh keeping, and generally using in Food processing factory ,supermarket, and hotel etc.
(4)Excellent quality, stable performance
Components:
(1) Condensing unit: Bitzer, Copeland, Maneurope (Danfoss),Yemoo,etc.
(2) High efficiency air-coolers
(3) Insulation Panel: PU panel
(4) Other accessories: world-famous brands, like Danfoss, Castle, Electric Control: Siemens, Schneider, CHNT, etc.
Cold storage for potato product information :
Dimension | Length (m) *Width (m)*Height (m). customized |
Panel | polyurethane insulation panel,38~46kg/m3, fire resistance |
Foaming material | BASF |
Panel thickness | 100mm, 120mm,150mm optional |
Steel cover | painted galvanized steel(stucco embossed aluminum, stainless steel, PVC stell optional). |
Panel connection | cam lock type, use hexagonal key to assemble and disassemble |
Type of door | hinge door, convex door, sliding door |
Temp.of cold room | -45~+20oC degree, optional, can be mixed temp in a project. |
Refrigeration unit | Bitzer, Copeland, Maneurope (Danfoss),Yemoo,etc. |
Refrigeration type | air cooled / water cooled, R134a, R404a, R507a or R22 |
Fittings | all necessary fittings are included, optional.. |
Place to assemble | indoor/out door(concrete construction building/steel construction building). |
Voltage | 220V/50HZ, 220V/60HZ, 380V/50HZ optional. |
Technical Data
Panels are joined together by means of tongue and groove and locked together by camlock on each side of the panel to ensure air tight joints.
-High density thermo insulated panel ranges from 38~46kg/m3 for perfect cold-room heat insulation efficiency.
-Low flammable PU foaming material is used in the cold room panel.
-Cam-lock design fastener to install cold room tightly and strongly
-Silica gel are used on the panel edge of the joint parts of each sandwich panel to ensure perfect sealing to avoid the cooling air leakage from the cold storage for potato or moisture inside the PU insulated panel for the best refrigeration and frozen storage result.
Cold room panel Testing Specification
No. | Inspection Item | Unit | Technology requirement | Inspection result |
1 | Density | kg/m3 | 38~46 | 43 |
2 | Compressing strength(10%deformation) | Kpa | ≥ 160 | 200 |
3 | Bending Strength | Kpa | ≥ 245 | 331 |
4 | Absording rate | % | ≤ 4 | 3 |
5 | Heating coefficient | W/m.k | 0.024 | 0.021 |
6 | Average burning time(vertical) | S | ≤ 30 | 3 |
7 | Average burning height(vertical) | s | ≤ 250 | 250 |
-Multiple types of optional thermo insulated cold storage for potato panel doors (Convex hinged door/Hinged door/Sliding door) with customized door size.
Thickness of PU panel | Application temperature |
100mm | -5°C or above |
120mm | -18°C or above |
150mm | -25°C or above |
Doors:
1).Swing door and Sliding door available.
2).Swing door: Manual, Automatic available etc.
3).Door panel made with special pressing technology PU material.
4).Door frame: color steel or stainless steel.
5).With Heater and anti-stuck system.
Cold Storage door for your optional:
No | Door type | Door size( stock size ) | Door heater voltage |
1 | Flush mounted hinged door | 800mm W*1900mm H | 24V / 36V |
2 | not flush mounted hinged door | 832mm W*1860mm H | 24V / 36V |
3 | sliding door | 832mm W*1860mm H | 24V / 36V |
4 | glass door | 725W*1775 mm | 24V / 36V |
