tetrafluoroethlene - Ethylene Copolymer ETFE (F-40)-lined pipe

Specifications

anti-corrosion
light weight, easy to install
smooth internal surface
excellent fatigue durability

tetrafluoroethlene - Ethylene Copolymer ETFE (F-40)-lined pipe











ETFE (F-40) is a kind of semicrystalline and semitransparent polymer, which is made by ethylene and tetrafluoroethlene through copolymerization with equal mol ratio. It keeps the good anticorrosion property of polytetrafluoroethylene, and has good heat resistance, wear resistance, radiation resistance and impact resistance and electrical insulation properties. It can apply the forming method of general thermoplastics to carry out machining, without surface self-lubricating ability, and the coefficient of friction is large, the tensile strength can be up to 500MPa. With long-term application temperature of -60~150°C, and thermal decomposition temperature of above 300°C, it almost proofs against all chemical substances.







Relative density	Softening temperature	Brittle temperature	Continuous application temperature	Chemical corrosion resistance
1.73-1.75	265-280°C	-100°C	150°C	Good
Brinell hardness	Elongation rate	Coefficient of friction	Coefficient of linear expansion	Yield strength
8.03kg/mm2	420-440%	0.2	9.4×10-5/°C	19-22MPa
Impact strength	Tensile strength	Water absorption	Dielectric constant	Arc resistance
93kg·cm/cm2	41-47MPa	<0.01	2.4-2.6	120s
