Specifications
Quickly earn money via waste plastic oil equipment1. Lower investment and higher profit
2. No pollution
3. ISO
Quick look through for better understanding for waste plastic oil equipment
1. The main parts of equipment
1.1. Rotary pyrolysis device
1.2. Automatic security environmental protection slagging system
1.3. Oil steam cyclone dust removal device
1.4. Quick condensing system
1.5. Waste gas purifying and reclaim burning system
1.6. Heat source supply system
1.7. Heat source environmental protection system
1.8. Central electronic control system
2. Technological Process
Crush waste tires and send them to rotary processor with negative pressure to catalyze and heat in order to get oil steam; oil steam shall pass light and heavy oil steam separator; light oil steam shall enter into the condenser and meanwhile residues shall be discharged automatically in succession. the liquefied part shall be condensed to rubber oil; and the part that cannot be liquefied shall be input into heating supply system for burning by way of combustion gas purification system.
3. Technical parameter of equipment
Item |
Content |
||
|
Model Pyrolysis plant |
HT-6 Continuous type |
HT-7 Continuous type |
HT-8 Continuous type |
Raw material |
Waste rubber Waste plastic |
Waste rubber Waste plastic |
Waste rubber Waste plastic |
Structure |
Horizontal rotation |
Horizontal rotation |
Horizontal rotation |
Handling capacity/24 hour |
12tons |
15 tons |
20 tons |
Fuel oil output/24 hour |
Tire: 45% Plastic: from 33% to 85% |
Tire: 45% Plastic: from 33% to 85% |
Tire: 45% Plastic: from 33% to 85% |
Working pressure |
Negative pressure |
Negative pressure |
Negative pressure |
Rotary speed |
0.4turn/m |
0.4turn/m |
0.4turn/m |
Power |
3KW |
3KW |
5.5KW |
Cooling mode |
Water cooling |
Water cooling |
Water cooling |
Rotary mode |
Internal gears |
Internal gears |
Internal gears |
Heating mode |
Hot wind |
Hot wind |
Hot wind |
Installation |
Have base |
Have base |
Have base |
Noise DB |
≤85 |
≤85 |
≤85 |
Reactor dimension |
5.1m*2.2m |
6m*2.2m |
6m*2.8m |
Weight |
30tons |
32tons |
34tons |
Production time |
20 days |
20 days |
20 days |
Space required |
About 400 m2 |
400 m2 |
400 m2 |
Working mode |
Continuous |
Continuous |
Continuous |
|
Consumption of water Per batch |
Little |
Little |
Little |
Warranty period |
1 year |
1 year |
1 year |
After-sales service |
Lifetime |
Lifetime |
Lifetime |
4. Environmental Protection
Without three wastes in the course of production.
