Main Feature
1 It includes the burner, pipes, base, cyclone, fan and so on, have the vertical type and rotary type
2, The cyclone is big, increase the working effeciency
3.Easy to installation and operating
4,Raw materials humility scope:20-70%. final scope:8-15%
Operating
We could send video for training or send technician to the working place
Working Principle
The fuel boiler generates hot air which mixes with wet materials and then is sucked into the pipes by the exhaust blower (fan) And then hot air is flowing and going though the curving pipes and buffer (drying chamber) of dryer, thus wet materials is finished to dry, and the dried materials are expelled out by the exhaust blower (fan)
| 3. Air dryer(vertical dryer and rotary dryer) | ||||
| Model | HGJ-4 | HGJ-6 | HGJ-7(rotary type) | HGJ-10(Rotary type) |
| Capacity | 300-400kg/h | 400-500kg/h | 600-800kg/h | 900-1200kg/h |
| Water evaporation quality | 60-80kg/h | 60-80kg/h | 180-220kg/h | 180-220kg/h |
| Consumption of wood | 15-20kg/h | 15-20kg/h | 25-30kg/h | 25-30kg/h |
| Working temperature in pipes | 150-180°C | 150-180°C | 150-180°C | 150-180°C |
| Input moisture | 20-30% | 20%-30% | 30%-60% | 30%-60% |
| Final drying | 8-14% | 8-14% | 8-14% | 8-14% |
| Barel diameter | 400mm | 600mm | 700mm(rotary body) | 1000mm(rotary body) |
| Drying pipe diameter | 220mm | 220mm | ||
| Max height of drying pipes | 3.2m | 3.2m | 3.2m | 3.2m |
| Thickness | 6mm | 6mm | ||
| Size of input materials | <5mm | <5mm | <5mm | <5mm |
| Weight | 1300kh | 1400kg | 4000kg | 5000kg |
| Power | 5.5kw | 7.5kw | 7.5kw+2.2kw+0.75kw | 11kw+2.2kw+0.75kw |
| Dimensions | 3x1x3.2m | 3.5x1x3.2m | 9x1.4x3.2m | 12x1.7x3.2m |
| Pieces of stove | 1piece | 1piece | 1piece | 1piece |
