Factory Direct Sale Crash Lock Bottom Folder Gluer 0086 15238032864

Factory Direct Sale Crash Lock Bottom Folder Gluer 0086 15238032864 photo-1
US$ 6,500 - 26,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Commodity, Food, Medical
Packaging Type:
Other, boxes
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao TianJin ShangHai etc
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Commodity, Food, Medical
Packaging Type Other, boxes
Packaging Material Paper
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 220/380V
Power 6KW
Place of Origin Henan, China
Brand Name HengYuan Brand
Model Number GK650CA
Weight 3000kg
Dimension(L*W*H) 8.4x1.3x1.45m
Certification ISO9001:2000
After-sales Service Provided Engineers available to service machinery overseas

Factory direct sale crash lock bottom folder gluer 0086 15238032864



Introduction for crash lock bottom folder gluer

1. Feeding: Automatic and continuous feeding

2. Adhesive:  Solute type

3. Basic box gluing methods: one side-gluing, both sides side-gluing, bottom gluing

4.The Machine consists of feeding, paper correction, prefolding, bottom locking, folding, full

pressing, press and so on.



Feeding section:

1. 5 independent feeding belts ensure the stability of paper feeding and easy calibration.

2. Continuously Variable Speeder to ensure the blank in even distance, and stable transmission

3. Pneumatic cutting lifting makes it easy to adjust the feeding belt.



Pre-folding section: Double-board structure (with a set of pre-folding knife)



Bottom-gluing section:

1. 3-board structure

2. Equipped with glue-applying device



Folding section : Double-board structure

Factory direct sale crash lock bottom folder gluer 0086 15238032864



Factory direct sale crash lock bottom folder gluer 0086 15238032864



Max speed

220m/min

Suitable paper

250-700g/m³

Past form

One-side edge pastes,two-side paste, bottom pastes

Feeding way

Automatic feeding

Machine weight

3000kg

Power

6kw,

Machine size

8.4x1.3x1.45m





Full pressing crash lock bottom folder gluer :

1.2-board structure



2.Two modes for pressing belt speeding:

1/Auto: set distance between boxes, pressing belt speed is the same as the machine, belt removes while opto-electronic detect it.



2/Manual: pressing belt conveys in a fixed speed and machine speed will not put any effect on it.



3.With counting device to count the finished boxes to match with  boxes regulating, easy to count and pack



Factory direct sale crash lock bottom folder gluer 0086 15238032864



Factory direct sale crash lock bottom folder gluer 0086 15238032864



Items

Paper size




Factory direct sale crash lock bottom folder gluer 0086 15238032864






A

Max:650mm

Min:110mm

Max:700mm

C

Max:55mm

Max:700mm

Min:70mm

E

Min:100mm

F

Min:25mm

Factory direct sale crash lock bottom folder gluer 0086 15238032864
