China supplier watered irrigation drip tape
Specification( Inlay belt line drip tape):
1.diameter:6mm,12mm,16mm
2.thickness:0.12mm-0.60mm
3.spacing:10cm,15cm,20cm,30cm,33cm,50cm.
4.flux:0.85-6.0L/H per hole
ing pressure:1bar
6.blasting pressure:2.7-3.0bar
7.roll length:1000m,1500m,2000m 2500m,3000m.or as customer's deamnds.
8.material:virgin raw material.
Application( Inlay belt line drip tape):
Pomeculture: Grape, Kiwi, Apple, Pear, Oranges, and etc.
Floriculture: Roses, Tulips, Carnations, Lilies for fresh cut flowers
Nursing Solution and Land Cultivation
Others: Flower gardens and Roadside trees.
Features( Inlay belt line drip tape):
Drip tape with double white line is suitable to pomeculture and perennial garden stuff by its superior durability.
Clogging free by its special structure.
It has excellent effect on orchard and crops cultivated outside or in slope.
Superior durability with the raw material of chemical-proof and anti-ultraviolet rays.
Drip tape with double white line is available to irrigate vast area at same time with low volume.
Drip irrigation systems have a host of benefits. They:
directly deliver water at a low-flow volume at soil level, reducing water waste
help maintain an even level of soil moisture
reduce risk of plant disease spreading due to overly moist foliage
have a 90% efficiency rating compared to traditional sprinkler systems (50-70%)
can be used with timers to automate watering
Flow rate---drippers spacing Chart
| Dripper spaccing | 100 | 150 | 200 | 250 | 300 |
| 0.9L/H | 0.85L/H | 0.85L/H | 1.2L/H | 1.2L/H | |
| 1.0L/H | 1.16L/H | 3.0L/H | 1.38L/H | ||
| 1.1L/H | 1.2L/H | 2.2L/H | |||
| 1.4L/H | 1.38L/H | 2.3L/H | |||
| 2.5L/H | 2.0L/H | 3.0L/H | |||
| 3.0L/H | 3.0L/H | ||||
1.WHAT MIL DRIP TAPE SHOULD I USE?
6 Mil(0.15mm)drip tape - Recommended for experienced growers only. Used for short season
crops that are not under plastic mulch. Minimal insect resistance.
8 Mil(0.2mm)drip tape - Is widely used throughout USA for basically all vegetable crops, under
plastic mulch or along rows.
10 Mil(0.25mm)drip tape - Is ised in heavy rocky soils and where insects and wire worms are a
problem. Also used for over winter crops like straeberries.
15 Mil(0.4mm) drip tape - Can be used for multi-year crops, including brambles and vineyards.
2.WHY SO MANY FLOW RATES?
- Row length will determine flow rate, zone size, or field size.
- Flow rates are also used to main lines, pump size, or water available
- Fields with row length over 500 Ft. require "low flow" drip lines or special larger diameter drip lines.
- Large diameter "low flow" will go up to 1500' row length.
- A more even distribution is achieved with low flow drip tape and larger zones.
3.HOW DO I MAINTAIN 1bar?
Drip line pressure is maintained with a pressure regulator in the head line. Also a pressure gauge
is needed there to assure the pressure is around1bar. before entering the drip lines. Pump
pressure must be higher.
4.WHY IS A FILTER NEEDED?
Water in the drip lines lead through a small turbulent channel to make each dripper drip the same
amount of water. Unfiltered water may clog these channels. Also well water must be filtered. Your
water source will determine the kind of filter needed. No filter needed for town or city water.
If this is not what you are looking for,click here to check our other products
Flat dripper drip irrigation tape
Agriculture drip irrigation pipe
Drip irrigation tape production line
