Vertical log band saw wood logs sawing machine used vertical band saws

FOB Price

USD $5,000 - $25,000 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port QINGDAO CHINA

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Band Saw	Use:	Woodworking
Style:	Vertical	Place of Origin:	Shandong, China	Brand Name:	Sawmill-world
Model Number:	MJ329	Usage:	Woodworking	Voltage:	380V
Power(W):	22kw	Dimension(LWH):	32503150900mm	Weight:	2200kg
Certification:	CE/ISO9001	Warranty:	1 Year	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Vertical log band saw wood logs sawing machine used vertical band saws

This lathe is mainly used to Vertical cut or slab-cut logs of a large or middle diameter or re-saw timbers into slabs and square logs of various specifications and it smoothly runs at a high efficiency.In combination with carriage, it will enlarge the working range and improve product quality and hence is the ideal equipment for wood working enterprises.

Detailed Images

Manually Wood Working Band Saw

Technical Parameter

woodworking band saw	MJ3210-5000	MJ329-5000	MJ329-3000	MJ318-3000
Diameter of saw wheel	1000mm	900mm	900mm	800mm
Rotational speed of saw wheel	750r·p·m	750r·p·m	750r·p·m	750r·p·m
Length of blade	6800mm	6400mm	6400mm	5800mm
Main motor power	22kw	15kw	15kw	11kw
Wood feeding car	Casting type	Welding type	Casting type	Welding type
Number of stakes clips	4 sets	4 sets	3 sets	3 sets
Number of wheels	2 sets	2 sets	2 sets	2 sets
Walking（forward, back）	Electric type	Electric type	Manually	Manually
Max. diameter of log sawed	800mm	700mm	700mm	650mm
Length of log sawed	6000mm	6000mm	4000mm	4000mm
Length of track	18000mm	18000mm	12000mm	12000mm
weight	3000kgs	2200kgs	2000kgs	1500kgs

The sawn wood

Auxiliary Machine

Our Service

Pre-sale Service:

1. Suggest to client suitable models of as customer need.
2. Introduce machine's structure and features in detail, explain the price component;
3. answer client concerned questions.
4.Sample testing support
5.View our factory

After-sale Service:

1. Start production as soon as receiving down payment.
2. Send photos of machine in manufacturing and finished photos to client, for your better learn about the machine's conditin.
3. Delivery machine in time, taking photos during loading, so you can "remote monitoring" your goods.
4. Documents and certificate available in time.
5. Training how to instal the machine,training how to use the mahcine

Packing & Delivery

Packing Details:

wood box or subject to customer requirement

Delivery Details:

Shipped in 15days after payment

Portable Horizontal Band Saw( Electric Model)

Max Sawing Wood Diameter 700-1600MM
Forward/backward: Manual or Electric
Setting Sawing Thickness:Electric/ Touch Screen

Large Size Horizontal Band Saw

Max Sawing log Diameter 1.8-3.5 Meters.
Touch Screen Setting Sawing Thickness
Power Option:Diesel or Electric

Multiple Heads Horizontal Resaw Band Saw

Touch screen setting sawing thickness.
Variable Frequency Speed Adjustable Feeding Conveyor

Portable Horizontal Band Saw(Diesel Model)

Max sawing wood diameter 700-1600MM
Manual Forward/backward and Setting sawing thickness
Popular in Virgin Forest Areas.

Mini Band Sawmill (Electric/Gasoline/Diesel Model)

Max sawing wood diameter:680MM
Forward/backward:Manual
Setting Sawing Thickness:Electric/Hydraulic

Precision Wood Horizontal Band Saw

Max sawing wood width:400-800MM
Max Sawing Wood Height:110MM
Min Sawing Wood Thickness:2MM
