PLC control system hydraulic dedicated fiber press machine
1.Product introduction:
- The machine used PLC control system, no-human operation system, horizontal and continue pushing bags , high speed and convenient to use.
- This machine can automatically connect to conveyor for auto-feeding.
- This machine mainly used for paper powder, tiny paper items materials.
- the completed material is briquetting, and can be removed directly, no need to bag easy to release after human knock.
2. Machine parameter:
Model |
JPW-AK100 |
Name |
PLC control system hydraulic dedicated fiber press machine |
Hydraulic power (Ton) |
100 |
| Bale size (W*H*L mm) | 320*320*(200-250) |
Feed opening size (L*W mm) |
500*320 |
Output (Ton/hr) |
0.4-0.8 |
Bale weight (Kg) |
5-15 |
Machine size (L*W*H mm) |
4000*920*1350 |
Brand |
CSJ |
Voltage (customizable) (V/HZ) |
380V / 50HZ |
Power (Kw/Hp) |
18.5Kw/25Hp |
Machine weight (kg) |
2600 |
3.Brand Of Baler Parts:
Crucial Components Allocation | |
HYDRAULIC TECHNIQUE |
REXROTH (Germany TECHNIQUE) |
HYDRAULIC ELEMENTS |
YUTIEN,HYDOR (TAIWAN Brand) |
SEALING PARTS |
HALLET (UK brand) |
ELECTICAL ELEMENTS |
DELIXI (Europe brand ) |
OIL PIPE |
ZMTE (Europe brand) |
MOTOR |
JIABAO (Brand-specific Customized hydraulic motor, without junction axis ,lower noise, no maintenance and energy saving, safe and reliable |
PUMP |
JINGGONG ( Taiwan investment) |
4.Details of machine photoes:
5.Models for options:
Model |
Hydraulic power(Ton) |
Bale size(W*H*L mm) |
Feed opening size(L*W mm) |
Bale weight (kg) |
Output (T/Hr) |
Voltage (customizable) (V/Hz) |
Power (kw/hp) |
Machine size (L*W*H mm) |
Machine weight(Ton) |
JPW-AK150 |
150 |
350*350*(200-300) |
500*350 |
10-16 |
0.65-1 |
380V/50HZ |
22KW/30HP |
4200*950*1399 |
3 |
JPW-AK200 |
200 |
450*450*(200-350) |
700*480 |
20-35 |
1.5-1.8 |
380V/50HZ |
30KW/40HP |
4260*1100*1800 |
4 |
6.Accessaries of complete equipment:
7.Certification:
8.Production process:
9.Packing for shipment:
10.In exhibition:
11.About us:
- Jiajing(CSJ)’s factory is located in Nantong, Jiangsu Province and our marketing department is located in Shanghai.
- We are commited in the research and development of hydraulic balers since 1995, our target is to do the latest, the most fashionable and the most high-end product.
- Our product which has 7 series about 50 size has widely used in paper making,textile,commodities,food etc..
- Got CE ISO TUV SGS and so on Certifications
- We are the supplier of Nike, Wal-mart, Unicharm, Dumex, JNJ,RT-Mart and many other World famous manufactures and wholesalers.
- Our company is the professional production factory of hydraulic baling press (compressed) machine, which has nearly 20 years experience in this field, and have been exported more than 90 countries.
- After many years technology research and development , we have obtained 21 national patents and 3 invention patents, and we have the rights of self-management import and export , No need the agent and the third party platform, that can save the customer's cost and time.
- At the same time, especially in equipment parts supply after clients use and the good after-sales service ,we have strong guarantee about this , hope you could pay attention about our company , thank you.
12.Our service:
- One year warranty for whole machine.
- Engineers available to service machinery overseas.
- 24 hours technical support by e-mail.
13.Contact us:
Contact person: Alice Fan
E-mail:jiabao801(@)
Website:
Cell: 0086-15821887659
Tel: 0086-021-61400508
Skype: csj-baler801
QQ: 2880619239
Add: Room 909, No.6 building, No.299 west Jiangchang Road, Shanghai China
