auto plastering machine
auto plastering machine
Plaster width: 800mm
Plaster thickness: 2-30mm
Plaster height: less than 3m
Brief introduction of auto plastering machine:
Application of auto plastering machine:
Auto plastering machine is residential buildings, office buildings indoor vertical
wall plaster of special equipment, can wipe the wall are: concrete walls, brick walls,
hollow walls, unburned brick wall, red brick, brick and other applicable gray foam.
Available mortar:
They are: white sand gray, gray cement, cement powder, dry mortar, stone, plaster,
foam mortar.
What is auto plastering machine?
Auto plastering machine is the machine which can plaster to wall, it belongs to
the field of construction machinery. It advantages that practical, wiping gray wall
construction eliminates the need for the RBI, the pumping of the other processes,
save time and effort, and easy to carry, simple operation, excellent quality
of the project and more. Especially some workers does not have any experience and
technology can use it.
Parameter of auto plastering machine:
Advantages of auto plastering machine:
1. Auto plastering machine can make the schedule advanced more
2. One plastering machine can top 10 professional plasters, it is not necessary to take
the stand, thus can save your cost of building shelves
3. Special chute and rope, smooth operation
4. The vertical flatness, smaller than human error, reducing the plasters labor intensity
and improve work efficiency
5. The dual-motor split run, lifting uniform smooth; runs expanse independently, wall
smooth and bright
6.Lightweight flexible: Widely used in the house, outside decoration, saving time, effort,
and material, greatly reducing the labor intensity, improve work efficiency
Using tools:
Operation of auto plastering machine:
1. Wet the wall one day early
2. Make the the position point fixed
3. Put the plastering machine close to the pole
4. Put the pole on the point,use the stand to make the machine and the wall parallel,
push the hydraulic control, fix the machine
5. Put the concrete into the machine, make the bar up
6. Open the button “start”, when complete, move to other place for plastering
Completed wall of auto plastering machine:
Packing and shipping of auto plastering machine:
Packing of auto plastering machine:
Auto plastering machine is divided into two parts, the main body in one wooden case,
the rest column parts in one wooden case, thus can avoid destroying the machine.
The dimension of main parts is 910*810*850mm, the column parts is 2500*250*260mm
Shipping of auto plastering machine:
Our nearest port is Qingdao, we can choose the most convenient port to you to deliver.
1. What should we do if our workers can not operate the auto plastering machine?
Do not worry about it, the machine is quite easy to operate, we have a professional
team to help you, they can help you train your plasters.
2. Do you have warranty?
The warranty of main parts is 12 months, the spare parts is 6 months.
3. If our plaster thickness is not the same as the your introduction, can it be used?
Thus we can improve it according to your requirement, we adopt advanced technology
to design the machine based on the customer needs.
4. I am not sure your machine can work well, any guarantee do you have?
We can ensure the quality, and our company hold that customer first, and you can
also come to our factory to test our machine.
Press start button ,machine goes up but the conveyor is not rolling?
1. switch on the conveyor switch.
2. check the chain on right side of machine , if the chain is rolling, that
mean the conveyor is loose. In this case, we have to tight the conveyor by
adjusting the screws on both side of machine closer to the plastering trowel.
How to maintain the auto plastering machine?
Rinse focus: around inside and outside the conveyor belt, a vibrator, templates, ash
bucket, hydraulic tube, climbing wheels, casters, and surface water.
There pole sand gray, wet and down with bags to clean; there are sand gray nylon
wheel, to disconnect the pole, with two hydraulic sleeve with high-pressure water play;
guide post within the oil window, wipe board reverse lever the active portion of the
electromagnetic clutch plate clutch, hydraulic sleeve, chain, wire rope and wire every
day, all the rugged play again oil.
Which kind of walls can auto plastering machine be used?
The brick-concrete wall, the cavity wall, the light brick wall and the baking-free brick
wall. It can use different materials to plaster the wall.
Our company hold that quality first, and be responsible for customers. We will
introduce the machine instruction to customer in detail, and choose the most suitable
machine to you. When you meet problems you are using the machine, you can
contact our after-service workers, we will help you solve as soon as possible.
Contact way:
Gongyi Dongxing Company
Add: Xinhua Road, Gongyi City, Henan Province, China
Tel: 86-371-85617836
Fax: 86-371-85617836
Website: https://img13.fr-trading.com
If you have any other questions, you can feel free to contact with Lily at any time!
