High Alumina Balls for Ceramic Grinding Media

Ningxia Baiyun Carbon Co., Ltd.
High Alumina Balls for Ceramic Grinding Media thumbnail-1
High Alumina Balls for Ceramic Grinding Media thumbnail-2
High Alumina Balls for Ceramic Grinding Media thumbnail-3
High Alumina Balls for Ceramic Grinding Media photo-1
High Alumina Balls for Ceramic Grinding Media photo-2
High Alumina Balls for Ceramic Grinding Media photo-3
US$ 800 - 1,000 MOQ: 1 Metric Ton
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Shape:
Ball
Material:
Alumina Cement
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao tianjin shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Shape Ball
Material Alumina Cement
Al2O3 Content (%) >=92%,95%

Specifications

High alumina balls for ceramic grinding media
1.Al2O3>92%,95%
2.Hardness>9
3.Volume density:3.64g/cm3-3.67g/cm3

High alumina balls for ceramic grinding media

Features:
1) Spheres (balls) or cylinders
2) Very excellent support and covering media
3) Function as support media for catalyst beds or other chemical beds in reactors or towers
4) Very excellent performances and stability in acid and other chemical surroundings
5) Very good chemical stability and low rate of water absorption
6) Can withstand high pressure and high temperatures
7) Can be even used in hot caustic service because they can resist over 10% sodium hydroxide service up to 60ºC, and 1% sodium hydroxide service temperature up to 100ºC
8) Can also resist the chemical corrosions of any acid (including organic and inorganic acids, but except HF acid), most of alkali and organic solvent
9) Will increase the distributors of liquid and gas, supporting and protecting the catalyst and avoid poisoned



Application: oil refinery, chemical, fertilizer, natural gas and environmental protection industries etc.



Technical Specification:

Type
Item

Feldspar

Feldspar-Mullite

Mullite

Mullite-Corundum

Corundum


Chemical composition%

Al2O3

20-30

30-45

45-70

70-90

≥90

Al2O3+SiO2

≥90

Fe2O3

≤1

Water absorption, %

≤5

Acid resistance , %

≥98

Alkali resistance,%

≥80

≥82

≥85

≥90

≥95

Thermal resistance,ºC

≥1300

≥1400

≥1500

≥1600

≥1700

Crushing strength
N/particle

ø3

≥120

≥140

≥150

≥160

≥200

ø6

≥400

≥420

≥440

≥480

≥500

ø8

≥480

≥520

≥600

≥620

≥650

ø10

≥600

≥700

≥800

≥900

≥1000

ø13

≥1000

≥1100

≥1300

≥1500

≥1800

ø16

≥1500

≥1600

≥1800

≥2300

≥2600

ø20

≥1800

≥2000

≥2300

≥2800

≥3200

ø25

≥2500

≥2800

≥3200

≥3600

≥4000

ø30

≥3000

≥3200

≥3500

≥4000

≥4500

ø38

≥4000

≥4500

≥5000

≥5500

≥6000

ø50

≥6000

≥6500

≥7000

≥8500

≥10000

ø75

≥10000

≥11000

≥12000

≥14000

≥15000

Bulk density, kg/m3

1300-1400

1400-1500

1500-1600

1600-1800

≥1800


Note: The data of bulk density is given for reference only, not as the acceptance criterion.
