Specification
| Model | LA170 | LA178 | LA186F | LA188F |
| Bore×Stroke (mm) | 70×55 | 78×62 | 86×70 | 88×78 |
| Displacement (cc) | 211 | 296 | 406 | 474 |
| Engine speed (rpm) | 3000 / 3600 | |||
| Max. output (hp) | 3.8 / 4.2 | 5.5 / 6 | 8.6 / 10 | 10 / 10.9 |
| Continuous output (hp) | 3.4 / 3.8 | 5 / 5.4 | 7.7 / 8.6 | 9 / 9.8 |
| Rated Power (Kw) | 2.5kW@3000rpm | 3.68kW@3000rpm | 5.7kW@3000rpm | 6.6kW@3000rpm |
| 2.8kW@3600rpm | 4kW@3600rpm | 6.3kW@3600rpm | 7.2kW@3600rpm | |
| Max. torque [Nm/(rpm/min)] | 9Nm/(2400rpm/m) | 13.2Nm(2400rpm/min) | 20.4Nm(2400rpm/min) | 23Nm/(2200rpm/m) |
| 8.4Nm/(2880rpm/m) | 11.9Nm(2880rpm/min) | 18.8Nm(2880rpm/min) | ||
| Compression ratio | 20:1 | 19:1 | 19.5:1 | |
| Fuel tank capacity (L) | 2.5 | 3.5 | 5.5 | 5.5 |
| Fuel consumption (g/kWh) | 280 | 275 | 265 | 343 |
| Oil capacity (L) | 0.75 | 1.11 | 1.65 | 1.65 |
| Dimension (L×W×H) | 332×392×416 | 383×421×450 | 412×470×494 | 417×441×500 |
| Net weight (kg) | 27 | 33 | 48 | 48 |
Product showcase
Manufacturing process
Optional parts
Crankshafts
Colors
Application
Quality control
Certificates
CE and ISO
1. packing manner: packed in 7 layer kraft carton with foam on two sides, 1pc/CTN
2. packing size: 478*460*521mm
3. loading quantity: 20': 240 units / 40'HQ : 630 units
4. shipping manner: usually by sea
1. Delivery time for engines & generators usually take 30 days after receive buyer's deposit.
2. Delivery time for water pumps & high pressure washers usually take 40 days after receive buyer's deposit.
3. For special period, for example, Chinese spring festival, the delivery time will be a little bit longer. So, in case of any impact on your sales, please arrange your purchase plan timely. If you place order during festival, please check with our sales the exact delivery time.
4. Also, in case of any delay in shipment, please arrange payment in time according to the payment terms agreed by both parties. Thank you for your cooperation !
1. We provide one year warranty for all of our products since the datd of B/L. If the machine break during he warranty period due to quality or assembling problem, we provide free spare parts to our customer for reparing. After expiration, we provide cost spare parts service. For any claim, please cooperate to provide necessary information to us for evaluation such as the serial number, pictures of the broken parts and working condition before the model broken. We will make record and improvement in case of same problem in the future.
2. We provide free technical consultant if you have any question about the usage of our products.
3. We can make OEM package & design as per request of our customer, such as customer brand, label, special model design, color, etc.
Year establish: Sep., 2000
Factory location: Hongkuan Industrial Park, Fuqing city, Fujian province, China
Factory area: 200,000 m2
Employee number: 800+
Engineers number: 50+
Main products: Air cooled single and twin cylinder gasoline & diesel engine, air cooled gasoline generators from 0.65-10kW, air cooled diesel generators from 2-10kW, water cooled multi-cylinder diesel generator from 8-2500kva, light towers, gasoline & diesel water pump from 1-4 inch, lawn mower from 16-22 inch, gasoline & diesel high pressure washers, welding generators.
Turnover at 2015 : 1.1 billion USD
We on fairs
Our team
1. Q: What's the MOQ for this model ?
A: The MOQ for this products is 10 units. But for sample order, we also accept 1-2 units.
2. Q: Do you have this model in stock ?
A: Usually, customers from different district have different request to the specification, such as color, speed, so it's hard to prepare stock in advance. But sometimes we will have several units left in stock, please ask our sales people to check for you.
3. Q: How about the production capacity ?
A: FYI, the current production capacity for our twin cylinder products is 50units/day. For gasoline products is 250 untis/day, for diesel products is 150 units/day.
4. Q: Can I mix several models in a container ?
A: Yes, this is acceptable. Please ask our sales to calculate the quantity for you.
