High Concentrator Ozone Therapy Machine / Medical Ozone Generator / Dental Ozone Generator

High concentrator ozone therapy machine / medical ozone generator / dental ozone generator

                                       ----------  CH-ZTW -----------

Features:

1. Corona Discharge technology
2. Built in Domestic Patent-Ceramic ozone tube with electric board
3. Feed outside oxygen source only with high ozone concentration
4. Ozone adjustable range: 20%-100%
5. Digital Timer : one or two recycle working time
6. Stylish, small size, plug& play
7. Changeable plug for different country.
8. Output : 3G/Hr, 5G/Hr, 6G/Hr, 7G/Hr.
9. Suitable used for the line which required high ozone concentration

Control panel:

Flow meter, Ozone adjuster, Oxygen input, Ozone output, Ampmeter, Switch, Timer, Working light, Power light

  High concentrator ozone therapy machine / medical ozone generator / dental ozone generator

High concentrator ozone therapy machine / medical ozone generator / dental ozone generator

How to use ?

1.Before use this machine,put it in a stable flat place which can hold its weight.

2.Use the power equipped with the machine.

3.The machine use for air purification,fisrtly attach the silicone tube into the ozone

outlet and then turn on the power.

4.Set the timer and then come out ozone, and put the tube into the room.

5.When use for room air purification, it requires nobody is present, after 30 minutes

people can walk into the room.

6.If use for water treatment, the air stone should be attached into the silicone tube

and put into the water.

7.Attention, the machine should be placed higher than the water, in case that the water

refluex occur.

  High concentrator ozone therapy machine / medical ozone generator / dental ozone generator

Applications:

>>Keep fresh, wash and remove the residual pesticides for vegetable and fruits,

>>Water treatment ozone generator, Small scale water treatment,

>>Water treatment for food factory, Home water sterilization

>>Hospital water supply sterilization, Home water treatment,

>>Laboratory ozone generator, Cosmetics disinfection,

>>Food package disinfection.

 Functions:

>> Laboratory: chemical oxidation for raw material of flavors and fragrances,

small water treatment experiment.

>>Beverage process industry: such as pure water, spring water and any other water

sterilization and disinfection.

>>Fruits & vegetables process industry: such us keep fresh, storage etc.

>> Food process industry: water, workshop, sterile room, equipments, tools.

>> Pharmaceutical industry: water, air conditioner, workshop, dressing room, sterile room etc.

>> Medical: ward, operating room, medical devices, sterile room etc.

  High concentrator ozone therapy machine / medical ozone generator / dental ozone generator
