Home > Consumer Electronics > Air Conditioner, Purifier & Humidifier > Air Purifier > Best for Aquaculture/water Treatment Heavy Metal Oxidizing Machine o3 Chemical Disinfector

Best for Aquaculture/water Treatment Heavy Metal Oxidizing Machine o3 Chemical Disinfector

Best for Aquaculture/water Treatment Heavy Metal Oxidizing Machine o3 Chemical Disinfector photo-1
Best for Aquaculture/water Treatment Heavy Metal Oxidizing Machine o3 Chemical Disinfector photo-2
Best for Aquaculture/water Treatment Heavy Metal Oxidizing Machine o3 Chemical Disinfector photo-3
Best for Aquaculture/water Treatment Heavy Metal Oxidizing Machine o3 Chemical Disinfector photo-4
US$ 500 - 4,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Power Source:
Electrical
Type:
Ozone Generator
Installation:
Other, Complete machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Power Source Electrical
Type Ozone Generator
Installation Other, Complete machine
Certification CE
Capacity (CFM) 98
Power (W) 480
Voltage (V) 220
Place of Origin Guangdong, China
Brand Name Ozocenter
Model Number CH-YFC

Specifications

Heavy metal oxidizing o3 chemical disinfector
1.Patent product
2.Easy operate
3.Movable with wheels
4.Built-in oxygen system

Best for aquaculture/water treatment heavy metal oxidizing machine

o3 chemical disinfector

(Model:CH-YFC)



Best for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfector

Best for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfector







Specifications

Item

Unit

NT-YFC5G

NT-YFC10G

NT-YFC15G

NT-YFC20G

NT-YFC30G

Oxygen flow rate

LPM

3

3.5

5

8

10

Ozone concentration

Mg/L

48.5~52.3

48.5~52.3

49.5~51.2

38.9~41.7

53.2~56.1

Ozone output

G/Hr

5

10~11

14.8~15.4

18.6~20

32~34

Power

KW

≤0.48

≤0.81

≤0.924

≤1.00

≤1.23

Current

A

2.2

3.6

4.2

4.5~4.7

5.6±5%

Voltage

V

220V/50HZ

NW

KG

64

86

89

92

97

Size

cm

45x50x84

50×66×95

45*93*118

>>Noted:

1. Above ozone capacity were tested under oxygen source

2. Net weight will be 10% different for different plug.







Operation Instruction

1.Before use this machine,put it in a stable flat place which can hold its

weight.

2.Use the power equipped with the machine;

3.The machine use for air purification,fisrtly attach the silicone tube into



>>the ozone outlet and then turn on the power;

4.Set the timer and then come out ozone, and put the tube into the room.

5.When use for room air purification, it requires nobody is present,



>>after 30 minutes people can walk into the room.

6.If use for water treatment, the air stone should be attached into the



>>silicone tube and put into the water.

.Attention, the machine should be placed higher than the water,in case



>>that the water refluex occur.



Best for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfectorBest for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfector



  High concentration carbon steel sprayed ozone vegetable and fruit washing generator

 Applications:

1. Waste water treatment , Chemical oxidation ,sterilization

2. Swimming pool and SPA water sterilization and disinfection

3. Domestic water sterilizer for housing estate

4. Aquaculture and aquarium water sterilization

5. Space air purification ,sterilizing room

6. Ozonated water for sterilization and disinfection ( sea food processing ,washing

>>beverage bottle and Barrel, washing floor )

7. Beverage and Drinking water disinfection

9.Decompose chemical residual from vegetable and fruit ,Eliminate bacteria and

>>virus for agriculture products tokeep fresh ,use for food processing, cold storage .

Best for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfectorBest for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfector

Best for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfector



  High concentration carbon steel sprayed ozone vegetable and fruit washing generator

QUALITY CONTROL

  Every procedure has personnel inspection. All the products must be

>>tested and qualified before packaging.



Best for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfectorBest for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfector



High concentration carbon steel sprayed ozone vegetable and fruit washing generator



  AFTER SERVICE

We provide 12month free maintenance.The buyer should return theproduct in the original conditions

>>to us and should bear the shipping costs for return. If any part is required to be replaced,the buyer

>>should also pay for the costs of the parts to be replaced.



Best for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfectorBest for aquaculture/water treatment heavy metal oxidizing machine o3 chemical disinfector



  High concentration carbon steel sprayed ozone vegetable and fruit washing generator

ABOUT US



what  we  do?



>>We Provide high-quality ozone generator for : Ozone generator wholesalers

>>Retailers and oneline shops (Ebay, Amazon...)  OEM-The custom-made ozone

>>generator are available. Upon customer's idea, drawings, photos etc.

>>ODM-The modification of the ozone generator after customer's selection is accepted.



 Excellent after-sales service:



>>1 year warranty again the manufacture defect, offer life time consultation on

>>problems occurred.2M silicone tube and 2PCS air stone gift for any ozone machine

>>order.Report on the making process.Marketing feedbacks tracing.



Why choosing us?·



>>Having 7 years production experienced .We are trusty business partner.·



>>Quality Controlled:Quality Control personnel check the quality at every stage of

>>production, from the incoming raw materials to the finished product. ·



>>CH-T Production Capacity: 3000 pcs per month. ·



>>We have serial products: ozone tube ,UV water sterilizers, ozone generators,

>>oxygen concentrators, protein skimmers, and filters, mixing pumps and other water

>>or air treatment spare parts.·



>>We supply OEM service according to customers' requests and give out professional

>>suggestions. Distributors Offer :  Welcome to be our distributor
