Fertilizer Tank is a cylindrical, epoxy coated, pressurized metal tank, resistant to the systems pressure, and connected as a bypass to the supply pipe of the head control.
1, It operates by differential pressure created by a partially closed valve, placed on the pipeline between the inlet and the outlet of the tank. Part of the flow is diverted to the tank entering at the bottom.
2, It mixes with the fertilizer solution and the dilution is ejected into the system.
3, The dilution ratio and the rate of injection are not constant.
4, The concentration of fertilizer is high at the beginning and very low at the end of the operation. However, this apparatus is still in service on a very small scale in some countries because of its low cost and easy manufacture.
|
Code |
Description |
Material |
|
Fertilize Valve |
SFF-25×10 |
1" |
Plastic |
SFF-40×10 |
1.5" |
Plastic |
|
|
Fertilize Tank |
SFG-10L×10 |
10L |
Plastic |
SFG-16L×10 |
16L |
Plastic |
|
SFGA-30L×10 |
30L |
Plastic |
|
SFGB-30L×10 |
30L |
Metal |
|
SFG-30L×16 |
30L |
Metal |
|
SFG-50L×16 |
50L |
Metal |
|
SFG-100L×16 |
100L |
Metal |
|
SFG-150L×16 |
150L |
Metal |
|
SFG-200L×16 |
200L |
Metal |
|
SFG-300L×20 |
300L |
Metal |
