Help CenterTire Shredder Machine-tire Recycling Plant
Related Products
-
Waste Rubber Shredding MachineUS$ 10,000 - 40,000MOQ: 1 Set -
Waste Rubber Shredding EquimentsUS$ 10,000 - 40,000MOQ: 1 Set
-
Waste Car/truck Rubber Shredding EquimentUS$ 10,000 - 40,000MOQ: 1 Set
-
Rolling Feeding ShredderUS$ 10,000 - 40,000MOQ: 1 Set
-
Used Tire Shredder MachinerUS$ 10,000 - 25,000MOQ: 1 Set
Specifications
twin shaft shredding machineno pollution to water and air
loser noise and higher torque
easy to maintainance and operation
Features:
Twin shaft constructed with claw knives for extremely powerful shredding capacity.
The knives are made of special alloy steel, heat-treatment, can be replace by piece and re-welded.
Motor combined with gear box drive, low-speed with high torque ensuring superior output.
The heavy pitch gear are precision manufactured from special alloy steel, heat-treatment, hardended for durability.
Oil bath lubricated gear box assures smooth running, lower noise, high torque and durability.
With low speed and high-torque designed, provide low noise and lesser dust, with friendly environment working place.
Low rotation rate, low noise and large moment of torsion. Mechanical or electrical overloading of the equipement is well avoided by the preset protective assembly, The machine is especially suitable for the onushing of those very-large and ultra-thick objects. (such as tyres, supporting boards, packing and barrels, which are usually difficult to break).
Rolling feeding shredder:
| Model | Feed size(mm) | Rotor diameter | Main machine speed | Rotary blade quantity | screen speed | screen motor power | Main Motor power | Dimension(mm) | Weight |
| LGSZ-S2880D | 800*520 | φ284 | 15 | 18 | 6 | 1.1 | 7.5+7.5 | 2000*1120*1330 | 2500 |
| LGSZ-S28100D | 1000*520 | φ284 | 15 | 24 | 6 | 1.1 | 11+11 | 2000*1120*1330 | 3000 |
| LGSZ-S4380D | 800*790 | φ430 | 15 | 20 | 6 | 1.1 | 15+15 | 2100*1420*1800 | 4000 |
| LGSZ-S43100D | 1000*790 | φ430 | 15 | 25 | 6 | 1.5 | 18.5+18.5 | 2400*1420*1800 | 4500 |
| LGSZ-S43120D | 1200*790 | φ430 | 15 | 25 | 6 | 1.5 | 22+22 | 2650*1420*1800 | 5200 |
| LGSZ-S51100D | 1000*960 | φ514 | 15 | 25 | 6 | 1.5 | 22+22 | 2900*1700*2300 | 5500 |
| LGSZ-S51120D | 1200*960 | φ514 | 14 | 32 | 6 | 2.2 | 30+30 | 3200*1700*2300 | 6500 |
| LGSZ-S51148D | 1480*960 | φ514 | 11 | 32 | 6 | 2.2 | 37+37 | 3600*1700*2300 |
8000
|
