semi automatic aluminium plastic tube filling sealing machine
Introduction:
The machine is made of stainless steel. The process is button-controlled. After manual tube-feeding, and tube position, it rotates continuously for quantity filling, auto-cut-off, heating sealing and tube ejecting. The whole process is pneumatic-controlled. It is easy to adjust filling quantity and speed.
Application:
The product is suitable for a variety of plastic tube and plastic composite tube filling, sealing, date printing, cutting the end, sealing appearance, neat, sealing strong, good stability. Widely used in cosmetic, pharmaceutical, food, chemical and other industries. Meanwhile, to meet the requirements of different viscosities can be filled with a variety of different specifications of the filling head.
Technical parameters:
Model |
JXFS-30 |
Voltage(V/Hz) |
AC 220/50 |
power (W) |
400W×2 |
Compressed Air(Mpa) |
0.6-0.8 |
Filling range(Ml) |
3-30, 5-75, 30-200 |
Air Consumption(m³/min) |
0.3 |
Filling Error |
±1% |
Capacity (pieces/min) |
20-30 |
Dimension(L×W×H)(mm) |
1230×700×1430 |
weight (kg) |
230 |
