Eco-friendly Light Duty storage rack with storage rack system
More pictures of Eco-friendly Light Duty storage rack with storage rack system
Aceally Boltless Rivet Shelving, being joined together with rivets, this shelving can be fitted at their length, width and height randomly. This type of shelving has a nice looking, fast and easy to disassemble and assemble without special tools. The height can adjust on 38.1mm centers. The shelf can be equipped with steel shelf, wood shelf or wire mesh deck.
Boltless Rivet Shelving spec:
| Part Name | Spec | Thickness | Length | Capacity |
| Angle Post | 37*37mm | 1.2~1.9mm | H24"~144" | 500~1000kgs |
| Heavy Angle Post | 47*47mm | 1.5~19mm | H24"~144" | 1000~2500kgs |
| concealed Slot Post | 38*38mm | 0.9mm | H24"~8" | 500~1000kgs |
| Double Rivet Beams I |
67*21mm 56*18mm |
1.5~1.9mm | L12"~96" | 50~150kgs |
| Double Rivet Beam II | 68*25mm | 1.5~1.9mm | L12"~96" | 100~250kgs |
Double Rivet Z style Beam |
54*22mm | 1.5*1.9mm | L12"~96" | 100~250kgs |
| Doubole rivet chanel beams I | 66*20*20mm | 1.9mm | L12"~96" | 150~300kgs |
| Doubole rivet chanel beams II | 68*25*25mm | 1.9mm | L12"~96" | 150~300kgs |
|
Heavy Doubole rivet chanel beams I |
66*20*20mm | 3.0mm | L12"~96" | 200kgs~400kgs |
|
Heavy Doubole rivet chanel beams II |
68*25*25mm | 3.0mm | L12"~96" | 200kgs~400kgs |
| Single rivet beams | 25*25mm | 1.9mm | L12"~48" | 50~100kgs |
| Heavy single Rivet Beams | 25*25mm | 3.0mm | L12"~48" | 100~150kgs |
| Double Rivet low Profile Beams | 50.8*1.8mm | 3.0mm | L12"~48" | 50~100kgs |
| Shelf Deck Supports I | 60*20mm | 1.5~1.9mm | L12"~48" | |
| Shelf Deck Supports II | 63*25mm | 1.5~1.9mm | L12"~48" | |
| Medium Density Fireboard | 1220*2440mm | 9~18mm | L12"~48" | |
| Tie Plate | 2.0mm | Without fumigation |
Boltless Rivet Shelving Pre-sale service
We offer no obligation professional consultation and design. Allow our experienced staff to assist you in designing a storage system that best suits your particular needs.
We also offer:
• Professional CAD Drawings
• Stamped Engineered Drawings
Custom sizes and colors are also available.
Custom designed and built to meet your specific needs and requirements.
After Sale Service
1.Professional engineer and application specialists respond to your requests efficiently;
2.Online via SKYPE MSN; Also through mail, voice phone message and fax if network is not accessible for
customer;
3.Follow up the case, record the entire process, report complaint to QC department;
4.QC will find defect from which department ,who is in charge to identify responsibility
record customer respond,suggestion,requirement.
The working flow of storage racks for your reference
Aceally (International) Group is a manufacturer of innovative and professional logistics equipment products for warehousing storage markets worldwide. Which specializes in light duty shelving, medium duty racking, heavy duty ones and various storage and shelving solutions for nearly 15 years. Please feel free to contact our highly knowledgeable staff and allow us the pleasure of proposing the most innovative and affordable solution to your material handling needs.
Our business scope as follows:
| Light duty rack | Selective pallet racking | VNA Pallet Racking | Wire mesh panel | Tool cabinet | |||||
| Modular wire shelving | Double deep pallet racking | Mezzanine Rack | Wire mesh container | Dock leveler | |||||
| Slotted angle shelving | Drive In pallet racking | Steel platform | Steel pallet | Supermarket shelving | |||||
| Boltless rivet shelving | Radio shuttle racking | Mobile shelving | Storage cage | Shopping basket | |||||
| Longspan shelving | Cantilever racking | Steel locker | Steel pallet box | Transportation cart | |||||
|
Website: or http://xmaceally.en.china.cn/ | |||||||||
Our products are 100% compatible to major brands such as Dexion, Redirack, Interlake etc. Designed to AS4084-1993 and complying with the European FEM regulations, SEMA and CE certificate. Our ability to design and custom build systems that suit your specific needs yet accommodate your strictest requirements allows us to propose material handling solutions for virtually any application.
Aceally at International Fair
Aceally Company Overview
