HSJ 200 Stone Machinery Supplier-- Offer

HSJ200       NUMERICAL CONTROL WIRE SAWING MACHINE

              - Flywheel diameter               1520mm

- Maximum vertical stroke of disc   1600mm

- Maximum depth of cutting        1500mm

- Maximum width of cutting         2000mm

-Maximum stroke of working table   3000mm

- Working table dimension          2500*1600mm

-Overall dimension                7000*5500*4200mm

- Capacity                        18Kw

-Weight                           8T

[Features]

 HSJ200 numerical control wire sawing machine is the dedicated equipment of irregular stone, this equipment is suitable for the marble, the granite, the artificial marble, the concrete board, and other special plane and French curve, and it is suitable specially for the major diameter circular arc board processing.

The Main characteristic as following:

1. The automaticity is high. The electrical control has used the computer numerical control technology, the main heading used servo electrical machinery which has stable performance, the reliable quality and the strong power, the pressure roller rotation electrical machinery has also used the step-by-step motor.

2. Reasonable structure and stable operation. This machine adopts Dragon Gate gantry construction, the two sides adopt a roller-type structure flywheel movements,  the elevator movement is Light, flexible and smoothly

3. Adjusting operating convenience.

4. Adopting the hydraulic pressure system. And this system adopts hydraulic accumulator and hydraulic pressure relief switch, makes the machine in good tension force and easy maintenance.
