Brief introduction- Collapsible Steel Reels for wire drawing machine
High quality, good dynamic balance.
Large loading.high strength
Model range: 800-5000mm
The product is manufactured in accordance with GB4004-83, JB/T7600.3-94 and DlN46395 standards. Its common carbon steel Q235 thin steel plate punched into corrugated type serves as the lateral plate; And its mandrel and major body are supported by four-groove reinforcing steel bars. The product has the characteristics of not only strengthening the strength of bobbin, but also having light weight of bobbin, which can be used for buncher, stranding machine, extruder, cabling machine and armouring machine.
Feature and advantage- Collapsible Steel Reels for wire drawing machine
1. stable arc,low splashing, beautiful seam
2. fast melting rate,high deposited efficiency
3. Smooth steady feeding.
4. Low welding costs.
5. High productivity and low electricity consumption.
6. Easy to operate. All-position welding.
7. Very low hydrogen content in the weld and lower nitrogen content. Excellent crack-resistance.
8. Little deformation after welding
Technical parameter- Collapsible Steel Reels for wire drawing machine
| Dimension | mm | |
| Flange OD. | d1 | 200-5000 |
| Barrel OD. | d2 | 300-1800 |
| Inner width | L2 | 300-2500 |
| Total height | L1 | 200-3000 |
| Center hole Diameter | h | As per need |
| Flange thickness | T | As per need |
| Boday materials | As per need |
