Pregelatinized starch machines

Specifications

1. Pregelatinized starch machines
2. capacity from 100kg/h-2ton/h
3. twin screw extruder
Flora:0086-15106920783

Pregelatinized starch machines/Modified starch machine



1. Description:

Pre-gelatinized starch is an effective and economical fluid loss agent in water based drilling fluids, which is a starch derivative. It is not bacterial degradation when at 120°C, environmentally acceptable and non-toxic. Modified Starch can produce a thin, slick, tough filter cake and promotes faster penetration rates with reducer friction. It can be used in all kinds of drilling fluid system. Pre-gelatinized starch is also sometimes "pregelatinized" to make them easier to dissolve during product manufacture. Modified starch is widely used in oil drilling, textile, paper and food industries.

 2. Raw materials: corn starch, cassava starch, potato starch

 3. Products: oil drilling starch, Pre-gelatinized starch

 4. Capacity: 100-150kg/h,200-240kg/h,300-400kg/h.500kg/h, 1ton/h, 2ton/h

 5. Flow Chart: Mixing---Extrusion---Drying---Grinding---Blending—Packing

 6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries

 7. Machines Materials: All the machines are made by stainless steel

 8. Technical Parameters

Model	Installed power	Real power	Output	Dimension
ZH65	81.5kw	53kw	100-150kg/h	21000x1200x2200mm
ZH70	115kw	76kw	200-240kg/h	23000x1500x2200mm
ZH85	145kw	100kw	300-400kg/h	20000x2000x3500mm
