Specifications
Gabion baskets (Boxes),mesh openning, 60*80mm, 80*100mm,
wire diameter: 2.2--3.0mm
Gabion baskets (Boxes) are structures which shall be made of hexagonal Galvanized/pvc/Alu-zinc coated double mild steel wire mesh.(See fig.I)
Gabion baskets shall be supplied in various lengths ,widths and heighes.For sizes & tolerances of dimensions (length x width x height),See Table Il.
In order to strengthen the baskets,all the edges of structure selvedged with wire of greater diamdter.See Table III.
Usualiy Gabion baskets which have bigger length than 2m is divided into cells by pandls (called disphgram) positioned per lmeter.
Gabion baskets are available in the following specification:
| Zinc Coated Steel Wire | Mesh Openning (mm) |
Wire Diameter (mm) |
60*80 |
2.2-2.4 |
|
75*95 |
2.4 |
|
80*100 |
2.6-2.7 |
|
80*120 |
2.6-2.7 |
|
90*90 |
2.6 |
|
90*120 |
2.6 |
|
100*120 |
2.7-2.8 |
|
100*135 |
2.7-2.8 |
|
120*150 |
3.0 |
|
60*80 |
2.2-2.4 |
|
75*95 |
2.4 |
|
80*100 |
2.6-2.7 |
|
80*120 |
2.6-2.7 |
|
90*90 |
2.6 |
|
90*120 |
2.6 |
|
100*120 |
2.7-2.8 |
|
100*135 |
2.7-2.8 |
|
120*150 |
3.0 |
Gabion Unit Standard Sizes:Custom Jumbo Sizes Available
| Gabion Unit Size | Capacity Cubic Yards |
Capacity Cubic Yards |
6x3x3 |
2 |
2 |
9x3x3 |
3 |
3 |
12x3x3 |
4 |
4 |
6x3x1.5 |
1 |
2 |
9x3x1.5 |
1.5 |
3 |
12x3x1.5 |
2 |
4 |
6x3x1 |
.666 |
2 |
9x3x1 |
1 |
3 |
12x3x1 |
1.33 |
4 |
Unit sizes available are the industry Standard Sizes or bespoke Non Standard Units.
