Hexagonal Wire Netting Gabions

Hexagonal Wire Netting Gabions photo-1
US$ 10 - 50 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
anruifeng
Model Number:
anruifeng
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin xingang port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name anruifeng
Model Number anruifeng
Material Other, Galvanized Iron Wire, Galvanized Iron Wire
Type Welded Mesh
Application Gabions
Hole Shape Hexagonal
Aperture 60X80mm
Wire Gauge 2.0---4.0mm

Specifications

Hexagonal Wire Netting Gabions
wire diameter ranges from 2.0mm to 4.0mm
openning: 80*100mm

Hexagonal Wire Netting Gabions are wire containers made of hexagonal wire netting. Wire diameter varies with the hexagonal nettings. For hexagonal wire netting with no pvc coating, the wire diameter ranges from 2.0mm to 4.0mm. For those PVC coated hexagonal wire netting, the outside diameter ranges from 3.0mm to 4.0mm. The wire of the outside frame edge is one wire gauge thicker than the wire used for hexagonal wire netting.

Features:
Economic. Just fill the stone into the gabions and seal it.
Simple installation. No special technology needed.
Weather proof under natural destroy, corrosion resistant.
No collapse even under big scope of deforming.
Sludge in the stones is good for plant growing. Mixed to form a integrity with the natural environment.

Good permeation can prevent the damage by hydrostatic.
Less transport freight. It can be folded together for transport and further installation.



Gabion boxes applications:
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside area.

Opening
(mm)

Wire Diameter(Metal Wire)    (mm)

Wire Diameter (PVC Coate)/ Inner/Outside(mm)

Strands

60X80

Ø2.0-2.8

Ø2.0/3.0-2.5/3.5

3

80X100

Ø2.0-3.2

Ø2.0/3.0-2.8/3.8

3

80X120

Ø2.0-3.2

Ø2.0/3.0-2.8/3.8

3

100X120

Ø2.0-3.4

Ø2.0/3.0-2.8/3.8

3

100X150

Ø2.0-3.4

Ø2.0/3.0-2.8/3.8

3

120X150

Ø2.0-4.0

Ø2.0/3.0-3.0/4.0

3
