Help CenterGalvanized Barbed Iron Wire
Related Products
Specifications
galvanized barbed iron wirebarb length 15-30mm
barb distance75-150mm
1or 2 strands 4points
normal twist or normal and count
galvanized barbed iron wire
Wire Materials:electric galvanized iron wire,hot dipped galvanized iron wire and after pvc coated iron wire in blue, green, yellow and other colors.
General Use: Barbed wire mainly serves in protecting of grass boundary, railway, highway, etc.
Packing:25 kg/disc or 50 kg / disc, the band tied with P.V.C , In waterproof paper in rolls , In coils by bulk, carton or pallet , in plastic bags hessian , PP woven cloth , or as your requirement.
Barb Weave : formal twist or formal and counter twist
Color : silver , blue , green , yellow and other colors as your requirement .
Features : aesthetic appearance and protective excellent performance, easy to install,
high safety factor, a good deterrent effect .
Specifications of barbed wrie
| Type | Wire Gauge (SWG) | Barb Distance (cm) | Barb Length (cm) | |
Electric Galvanized Barbed Wire; Hot-dip zinc plating barbed wire | 10# x 12# | 7.5-15 | 1.5-3 | |
| 12# x 12# | ||||
| 12# x 14# | ||||
| 14# x 14# | ||||
| 14# x 16# | ||||
| 16# x 16# | ||||
| 16# x 18# | ||||
| PVC coated barbed wire; PE barbed wire | before coating | after coating | 7.5-15 | 1.5-3 |
| 1.0mm-3.5mm | 1.4mm-4.0mm | |||
| BWG11#-20# | BWG8#-17# | |||
| SWG11#-20# | SWG8#-17# | |||
| PVC PE coating thickness: 0.4mm-0.6mm; different colors or length and gauge are available at customers request. | ||||
the detaills on the 20 feet container : ( other kinds as your request)
Wire gauge | Weight 10kgs per coil | Weight 15kgs per coil | Weight 25kgs per coil | |||
1X20FCL | Length | 1X20FCL | Length | 1X20FCL | Length | |
16#X16# | 15TONS | 160M | 15TONS | 240M | 16TONS | 400M |
16#X14# | 16TONS | 125M | 16TONS | 180M | 17TONS | 300M |
14#X14# | 17TONS | 100M | 17TONS | 150M | 18TONS | 250M |
14#X12# | 18TONS | 80M | 18TONS | 120M | 19TONS | 200M |
12#X12# | 19TONS | 65M | 19TONS | 100M | 20TONS | 160M |
