Specifications
1high strength, fine corrosion resistancelonged service life
3.fine penetrability,water absorptivity
4.fast install
BC Series Pad Fan Cooling System :
Features:
1) Corrugated paper with the spatial crossing linking technology, high absorbability,
high water resistant, antimildew and long service life.
2)Large evaporation area, cooling efficiency as high as 80%.
3)The product absorbs water naturally, with fast speed of pervasion and lasting effectiveness.
One drop of water can diffuse within 4~5 seconds.
4) The product does not contain phenol which is irritant to the skin and the like chemical products.
It is safe, energy saving, environmental protective, economic and durable.
5) Galvanized sheet and aluminum panel optional.
Specification of Pad Fan Cooling System :
1). Height: 600mm, 700mm, 1200mm, 1500mm, 1800mm, 2000mm
2). Width: 300mm, 400mm, 500mm, 600mm,
3). Thickness: 100mm, 150mm
4). We can offer others size which buyer need.
Cooling Pad Wall packed detailed:
Cooling pad parameters table
Model |
Height mm |
Width mm |
Thickness mm |
Corrugation height mm |
Corrugation angle |
HS-7090 |
1000~2000 |
600 |
100,150,200 |
7 |
45 º ×45 º |
Note: Other dimensions can be customized according to customer’s requirements. The above mentioned parameters are for reference only.
Paper pad performance
Paper pad thickness |
Air speed m/s |
0.60 |
0.80 |
1.00 |
1.20 |
1.40 |
1.60 |
1.80 |
2.00 |
100mm |
Pressure drop Pa |
7.0 |
8.0 |
11.0 |
16.0 |
20.0 |
24.0 |
28.0 |
35.0 |
Efficiency % |
82.0 |
80.0 |
78.3 |
76.5 |
74.9 |
73.3 |
72.0 |
70.8 |
|
150mm |
Pressure drop Pa |
10.0 |
13.0 |
18.0 |
23.0 |
30.0 |
38.0 |
45.0 |
54.4 |
Efficiency % |
92.5 |
91.3 |
90.0 |
88.7 |
87.5 |
86.5 |
85.4 |
84.5 |
Furthermore, we also manufacture and sell another kind of product that can match with the cooling pad: ventilation fan .We share the benefits with you and we are willing to develop with you together. Should you be interested in any of our products and have any question, please don’t hesitate to contact me.
