Product Details
Place of Origin: | Shandong, China | Brand Name: | TY | Model Number: | DIN6899A |
Product Description
Specifications
rigging DIN 6899 A Thimble china supplier1.Size: 2.5*3-24*26mm
2.NW: 0.50-62.00kg/100pcs
rigging DIN6899A thimble china supplier
DIN6899 A TYPE WIRE ROPE THIMBLE | |||||||
Item | Size | Dimensions(mm) | Weight/kg | ||||
A | B | C | D | E | |||
TY002 | 2.5MM | 3 | 21.5 | 10 | 28 | 1 | 0.0014 |
TY003 | 3MM | 3.5 | 23.5 | 11 | 30 | 1 | 0.0035 |
TY004 | 4MM | 4 | 26.5 | 12 | 34 | 1 | 0.0042 |
TY005 | 5MM | 5 | 28 | 13 | 36 | 1 | 0.006 |
TY006 | 6MM | 6 | 30 | 14 | 38 | 1 | 0.0076 |
TY007 | 7MM | 7 | 33 | 15 | 43 | 1.2 | 0.011 |
TY008 | 8MM | 8 | 35 | 16 | 46 | 1.2 | 0.017 |
TY009 | 9MM | 9 | 39 | 18 | 50 | 1.2 | 0.021 |
TY010 | 10MM | 10 | 43 | 20 | 56 | 1.5 | 0.035 |
TY011 | 11MM | 11 | 47.5 | 22 | 63 | 1.5 | 0.037 |
TY012 | 12MM | 12 | 51.5 | 24 | 68 | 1.5 | 0.0053 |
TY013 | 13MM | 13 | 56.5 | 26 | 75 | 2 | 0.072 |
TY014 | 14MM | 14 | 61 | 28 | 82 | 2 | 0.083 |
TY015 | 16MM | 16.5 | 69.5 | 32 | 91 | 2.5 | 0.123 |
TY018 | 18MM | 18 | 78 | 35 | 102 | 3 | 0.185 |
TY020 | 20MM | 20 | 86.5 | 40 | 114 | 4 | 0.315 |
TY022 | 22MM | 22 | 95 | 44 | 126 | 4 | 0.365 |
TY024 | 24MM | 24 | 103.5 | 48 | 135 | 4 | 0.39 |
TY028 | 28MM | 28 | 120.5 | 56 |
