CHAIN OPEN LINK ANCHOR CHAIN/STUDLESS ANCHOR CHAIN China Supplier
Negotiable
MOQ: 2 Tons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
TY
Model Number:
STUDLESS
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CHAIN OPEN LINK ANCHOR CHAIN/STUDLESS ANCHOR CHAINNegotiableMOQ: 2 Tons -
STUD LINK ANCHOR CHAINNegotiableMOQ: 2 Tons
-
STUD LINK ANCHOR CHAIN CHINA SUPPLIERNegotiableMOQ: 2 Tons
-
CHAIN STUD LINK ANCHOR CHAIN CHINA SUPPLIERNegotiableMOQ: 2 Tons
-
ANCHOR CHAIN STUD LINK ANCHOR CHAIN CHINANegotiableMOQ: 2 Tons
Place of Origin
Shandong, China
Brand Name
TY
Model Number
STUDLESS
Structure
Welded Chain
Function
Conveyor Chain
Material
Alloy
Standard or Nonstandard
Standard
Specifications
OPEN LINK ANCHOR CHAIN/STUDLESS ANCHOR CHAIN china1.High quality and service
2.Break load tested
3.Bending stress
CHAIN OPEN LINK ANCHOR CHAIN/STUDLESS ANCHOR CHAIN china supplier
MATERIAL:U1:CM370 U2:CM490 U3:CM690Ø
| OPEN LINK ANCHOR CHAIN/STUDLESS ANCHOR CHAIN ,LINK SIZE(6*3.6D),TEST LOAD AND WEIGHT | ||||||||||
DIAMETER |
CHAIN LINK SIZE | BM1 U1 OPENLINK CHAIN | BM2 U2 OPEN LINK CHAIN | BM3 U3 OPEN LINK CHAIN | APPROX WEIGHT | |||||
L OUTSIDE LENGTH
| B OUTSIDE WIDTH | PROOF LOAD | BREAKING LOAD | PROOF LOAD | BREAKING LOAD | PROOF LOAD | BREAKING LOAD | 27.5M | ||
| INCH | MM | MM | MM | KN | KN | KN | KN | KN | KN | KG |
| 1/2 | 12.5 | 75 | 45 | 28.75 | 57.81 | 41.20 | 82.60 | 56.40 | 112.80 | 85.41 |
| 9/16 | 14 | 84 | 50.4 | 34.78 | 69.93 | 51.00 | 101.90 | 70.76 | 141.51 | 106.55 |
| 5/8 | 16 | 96 | 57.6 | 47.10 | 94.72 | 66.20 | 132.30 | 92.42 | 184.83 | 139.43 |
| 11/16 | 17.5 | 105 | 63 | 56.35 | 113.31 | 78.89 | 157.78 | 110.55 | 221.10 | 178.35 |
| 3/4 | 19 | 114 | 68.4 | 66.42 | 133.57 | 93.60 | 187.20 | 130.32 | 260.64 | 217.68 |
| 13/16 | 20.5 | 123 | 73.8 | 77.33 | 155.49 | 108.64 | 217.27 | 151.70 | 303.42 | 229.14 |
| 7/8 | 22 | 132 | 79.2 | 89.06 | 179.08 | 125.40 | 250.90 | 174.40 | 349.40 | 264.49 |
| 15/16 | 24 | 144 | 86.4 | 105.98 | 213.25 | 149.90 | 298.90 | 207.90 | 415.48 | 341.82 |
| 1-1/16 | 26 | 156 | 93.6 | 124.38 | 250.12 | 175.40 | 350.80 | 244.00 | 488.00 | 369.94 |
| 1-1/8 | 28 | 168 | 100.8 | 144.26 | 290.08 | 203.80 | 406.70 | 283.00 | 566.00 | 427.04 |
| 1-3/16 | 30 | 180 | 108 | 165.6 | 333.00 | 234.20 | 467.50 | 324.90 | 649.80 | 490.98 |
| 1-1/4 | 32 | 192 | 115.2 | 188.42 | 378.88 | 265.60 | 531.20 | 369.60 | 739.30 | 559.65 |
| 1-5/16 | 34 | 204 | 122.4 | 212.7 | 427.72 | 299.90 | 599.80 | 417.30 | 834.60 | 671.52 |
| 1-7/16 | 36 | 216 | 129.6 | 238.46 | 479.52 | 336.10 | 672.30 | 467.80 | 935.70 | 707.85 |
| 1-1/2 | 38 | 228 | 136.8 | 265.7 | 534.28 | 374.40 | 748.70 | 521.30 | 1042.50 | 788.98 |
| 1-9/16 | 40 | 240 | 144 | 294.4 | 592.00 | 414.50 | 829.10 | 577.60 | 1155.20 | 869.36 |
| 1-5/8 | 42 | 252 | 151.2 | 324.58 | 652.68 | 457.70 | 915.30 | 636.80 | 1273.60 | 959.30 |
| 1-3/4 | 44 | 264 | 158.4 | 356.22 | 716.32 | 502.70 | 999.60 | 698.90 | 1398.00 | 1111.25 |
1-13/16 | 46 | 276 | 165.6 | 389.34 | 782.92 | 548.80 | 1097.60 | 763.90 | 1527.00 | 1152.07 |
| 1-7/8 | 48 | 288 | 172.8 | 423.94 | 852.48 | 597.80 | 1195.60 | 831.70 | 1663.50 | 1256.26 |
| 2 | 50 | 300 | 180 | 460 | 926.09 | 648.80 | 1293.60 | 902.50 | 1805.00 | 1360.41 |
| 2-1/16 | 52 | 312 | 187.2 | 497.54 | 1000.48 | 697.63 | 1395.26 | 976.14 | 1952.28 | 1485.61 |
| 2-1/8 | 54 | 324 | 194.4 | 536.54 | 1078.92 | 752.33 | 1504.66 | 1052.68 | 2105.36 | 1648.08 |
| 2-3/16 | 56 | 336 | 201.6 | 577.02 | 1160.32 | 809.09 | 1618.18 | 1132.10 | 2264.20 | 1715.97 |
| 2-5/16 | 58 | 348 | 208.8 | 618.98 | 1244.68 | 867.91 | 1735.82 | 1214.40 | 2428.80 | 1844.50 |
| 2-3/8 | 60 | 360 | 216 | 662.4 | 1332.00 | 928.80 | 1857.60 | 1299.60 | 2599.20 | 1973.29 |
| 2-7/16 | 62 | 372 | 223.2 | 707.3 | 1422.28 | 991.75 | 1983.50 | 1387.68 | 2775.36 | 2101.56 |
| 2-1/2 | 64 | 384 | 230.4 | 753.66 | 1515.52 | 1056.77 | 2113.54 | 1478.66 | 2957.32 | 2298.47 |
| 2-9/16 | 66 | 396 | 237.6 | 801.5 | 1611.72 | 1123.85 | 2247.70 | 1572.52 | 3145.04 | 2398.10 |
| 2-11/16 | 68 | 408 | 244.8 | 850.82 | 1710.88 | 1192.99 | 2385.98 | 1669.26 | 3338.52 | 2522.88 |
| 2-3/4 | 70 | 420 | 252 | 901.60 | 1813.00 | 1264.20 | 2528.40 | 1768.90 | 3537.80 | 2697.65 |
