brown/green/yellow-green/black-coated color evaporative cooling pad for poultry farm/greenhouse/factory
Professional industrial/agricultural cooling system
High temperature control, hot air cooling
Can work with exhaust fan
Corrosive-resistant, high hygroscopicity, most economic and efficient
Wall mounted, easy installation
CE certificate
Working principle:
Jinlong cooling pad is made of corrugated fiber paper which is covered by thin layer water film. When the outside hot air passes through the paper, water on the thin film will absorb the heat in the air and evaporate into vapor. And the cool and humid air will enter the room. The processing is just like the wind blowing through the water level.
Jinlong Cooling Pad Features:
1. High quality raw material: Jinlong Cooling Pad is Made of corrugated fiber paper with the spatial crossing linking technology: high absorbability, high water resistant and anti-mildew. After integrating some special chemical composition and post-processing, the cooling pad is anti corrosive, high strength with long service life. It can supply enough surface area for heat exchange of the water and air and also can purify the air as a natural filter.
2. High hygroscopicity: to absorb water naturally, with fast speed of pervasion and lasting effectiveness. Water drops can diffuse within 4-5 seconds. The natural absorption height is 60-70mm/5 minutes, as 200mm/1.5 hours, reaching the international standard.
3. Specific stereoscopic structure: large evaporation area, and cooling efficiency can be as high as 80%. After a special formula and process, the pad surface has good performance in absorbing water while preventing water droplets coming out from the surface.
4. Instant-drying: when water stops flowing on pad surface, its protection coat will dry very soon. In this case, animalcule can not live on the surface which prevents the growing of algae.
5. No phenol in the raw material, which is irritant to skin: safe, energy saving, environmental protective, economic and durable.
6. No micro hole on the surface: preventing the algae from living in deep part of pad. Algae will fall automatically when the pad become dry.
7. Frame: galvanized, aluminum alloy or stainless steel, beautiful and practical, high-strength, easy to remove.
Jinlong Cooling Pad---Various colors for your selection:
Technicall parameter of Jinlong Cooling Pad: Special dimension can be customized according to customers' requirements.
Would be great and highly appreciated if you could kindly inform us the model you want, with quantity, delivery time and destination port or other specific requirements when you send us inquiry. We will give you best quotation with more details ASAP.
"Cooling pad + ventilation fan" tunnel ventilation is the most economical and efficient cooling way in summer. Reasonable design and installation of cooling pad with ventilation fan can control the temp at 30 degrees in the poultry house even at the hottest weather. Thus it can reduce the negative effect of high temperature on the birds to the minimum.
Installation:
1. The cooling pad and the fan are always oppositely arranged, and the cooling pad is installed on the wall surface facing monsoon wind.
2. Submersible pump should be installed under water in the pool to keep the water source clean and the ground neat and beautiful. After the installation, the water distribution is even and no leaking because of its tight structure.
