Specifications
Farm chicken cage feedingFeed hopper for 3 tiers to 6 tiers
Service for 5000 birds one time
Save much labor
TAIYU Save Labor Cost Farm Chicken Cage Feeding
Farm Chicken Cage Feeding- Company Introduction
Quality- According to climate and poultry house design of different countries, we own different class of quality to suitable the market request
Agent- Good quality reputation and proper and efficient service, now our company own agents in some countries like Nigeria, Kenya, Uganda,Tanzania, Zambia, Malawi, Zimbabwe and welcome your joining
Connection- Sandy Wang 0086 18831186192, Skype: hysandywang, welcome your call and message
Farm Chicken Cage Feeding- Cage Specifications
Type | L1 | L2 | L3 |
Size per unit(L*W*H) (M) | 1.88 by 1.8 by 1.6 | 2.0 by 1.8 by 1.62 | 2.2 by 2.4 by 1.65 |
Size per cell (CM) | 47by 32 by 37 | 40 by 38 by 38 | 43 by 40 by 40 |
Set capacity | 96 birds | 120 birds | 120 birds |
Cell capacity | 4 birds per cell | 4 birds per cell | 4 birds per cell |
Door | 4 doors | 5 doors | 5 doors |
Surface treatment | Cold galvanized | Cold galvanized | Hot deep galvanized |
Lifespan | 8 years | 12 years | More than 20 years |
Raise period | 16 weeks to 72 weeks | ||
Accessories | Cage, cage frame, water pipe, drinkers, feeders, other necessary fittings Drinking system is automatic | ||
Type | L4 | L5 | L6 |
Size per unit(L*W*H) (M) | 2.0 by 2.4 by 1.77 | 2.0 by 3.0 by 1.95 | 2.2 by 3.0 by 1.95 |
Size per cell (CM) | 47by 32 by 37 | 40 by 38 by 38 | 43 by 40 by 40 |
Set capacity | 160 birds | 160 birds | 160 birds |
Cell capacity | 4 birds per cell | 4 birds per cell | 4 birds per cell |
Door | 5 doors | 5 doors | 5 doors |
Surface treatment | Cold galvanized | Cold galvanized hot deep galvanized | Hot deep galvanized Cold galvanized |
Lifespan | 8 years | 8-30 years | 8-30 years |
Raise period | 16 weeks to 72 weeks | ||
Accessories | Cage, cage frame, water pipe, drinkers, feeders, other necessary fittings Drinking system is automatic | ||
Farm Chicken Cage Feeding- Feeding Sowing
Farm Chicken Cage Feeding- Feeding Technical Data
Item | Specification |
Source type | AC, 3-Phase |
Rated power | 0.75KW-0.11KW |
Rated voltage | 220V/380V |
Outline size | L by W by H=(2.3-2.7) by (1.2-1.5) by (2.0-2.25) |
Hopper size | L by W by H= 0.66m by 0.256m by 0.5m |
Working average rate of the hopper | Around 15g/m |
Feed capacity of each hopper | 35KGS-100KGS/Piece |
Working speed | 10-15 Meters/Min |
Structure weight | 550KG |
Supporting orbits | Thickness=3.0mm Diam=50mm |
Orbits material | Hot deep galvanized pipe |
Transverse auger conveying feeding equipment | Diameter=75mm to 150mm |
Connected with the silo | 5000KGS TO 15000KGS |
Farm Chicken Cage Feeding- Other feeding system
Feed trough
Trolley feeding
Feed mill
Farm Chicken Cage Feeding- My contacts
