Specifications
Automatic poultry battery cage for nigerian farmFeeding system
Egg collection system
Manure removal system
Warehouse lagos
TAIYU Automatic Poultry Battery Cage for Nigerian Farm
Automatic poultry battery cage for Nigerian farm - cage introduction
Item |
Broiler Cage |
Egg Laying Chicken Cage |
3-tier /2-door |
3-tier /5-door |
|
Set capacity |
120 birds |
120 birds |
Cell capacity |
10 birds |
4 birds |
Cage size |
5.25 by 6.89 by 5.4 feet |
7.2 by 7.9 by 5.0 feet |
Cell size |
31.5 by 13.8 by 16.54 inch |
16.9 by 16.6 by 16.5inch |
Fittings |
Cages, cage frame, water pipe, drinkers, feeders, other necessary fittings. Drinking system is automatic, after installation then put birds and food. |
|
Materials |
Q195 steel wire , Q235 steel wire |
|
Recommended Sets/Row |
10 sets to 55 sets | |
Lifespan |
5 years to 30 years as different countries' climate and poultry house design |
|
Automatic poultry battery cage for Nigerian farm - automatic feeding system
Item |
Specification |
Source Type |
AC, 3-Phase |
Rated Power |
0.75KW - 0.11KW |
Rated Voltage |
220V/380V |
Outline Size |
L by W by H = (2.3-2.7) by (1.2-1.5) by (2.0-2.25)m |
Hopper Size |
L by W by H = 0.66m by 0.256m by 0.5m |
Working Average Rate of the Hopper |
Around 15 g/m |
Feed Capacity of each Hopper |
35KGS - 100 KGS/piece |
Working Speed |
10 - 15 Meters/Min |
Structure Weight |
550KG |
Supporting Orbits |
Thickness = 3.0mm Diam = 50mm |
Orbits Material |
Hot deep galvanized Pipe |
Transverse Auger Conveying Feeding Equipment |
Diameter = 75mm to 150mm |
Connected with the Silo |
5,000KGS to 15,000KGS |
Automatic poultry battery cage for Nigerian farm - automatic egg collection system
Items |
Specifications |
Size(L×W×H) |
(2.2~2.8) M × (1.0~1.5) M × (2.0~2.6) M |
Source Type |
AC,3-Phase Source |
Rated Voltage |
380V |
Rated Power |
0.75~3.0KW |
Egg collection ability |
>3000 PIECES/HOUR |
Egg Broken Rate |
≤1% |
Belt Working Speed |
1~3 M/MIN |
Working Type |
4 tiers working together |
Paint Thickness |
≥0.05MM |
Machine Weight |
700KGS |
Egg collecting belt |
Common one and Best quality imported from Italy |
Egg collecting belt width |
100MM |
Automatic poultry battery cage for Nigerian farm - automatic manure removal system
| Components | driving system , scraper , angle pulley , stroke limitation , panel control box and rope |
| working | control 2 rows or 3 rows |
| Features |
1. manure removed effectively, save labor cost 2.easy installation , maintenance and operation 3. save electricity, one day open one time |
Automatic poultry battery cage for Nigerian farm - Nigeria farm
Automatic poultry battery cage for Nigerian farm - Foreign agent for your reference.
Country |
Customer name |
Address |
Telephone No. |
KENYA |
XXX PAUL |
P.O BOX XXX,XXX PLAZA NAIROBI |
00254XXXXXXXX5 |
TANZANIA |
XXX ALI KHAMIS |
TIP NO. 1XXXXXXX2 |
00255XXXXXXX2 0255XXXXXXX6 |
UGANDA |
BENJAMIN XXX |
XXX TOWN COUNCIL WAKISO DISTRICT |
00256XXXXXXXX6 |
NIGERIA |
BOLAJI XXX |
XXX, LAGOS-BADAGRY EXPRESS WAY |
0023470XXXXXXX9 |
|
Welcome joining,visit customers every year. Welcome to visit agent's office or farms to check the quality and get more details. The above information is just some agents for refference, please call or email us to get the full information. | |||
Automatic poultry battery cage for Nigerian farm - Warehouse in Lagos
Automatic poultry battery cage for Nigerian farm - Customers pick up their cages at our warehouse
