Auto-coal Buring Heating Machine(Coal Feeding Manually)

Name: Auto-coal Buring Heating Machine(Coal Feeding Manually)
Brand: SANHE
SKU: 138094677
Availability: InStock

US$ 1,789 - 4,779 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Air Heater

Power Source:

Other, Blind coal,coke

Shandong Yuyun Sanhe Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Air Heater

Power Source Other, Blind coal,coke

Place of Origin Shandong, China

Brand Name SANHE

Model Number SANHE FSH-20

Dimension(L*W*H) 2000mm*1100mm*2200mm

Weight 850KG

Voltage 380V/220V

Power(W) 5KW

Certification CE/ISO9001:2008/BV

Warranty one year

Features of SANHE Auto Coal-buring Heating Machine

1) Heater exchanger adopt special three-pass design, remove dust automatically.

2) Equipped with auto-alarm and auto-protection device.

3) Fan blowers start on and off automatically or manually.

4) Optional computer controlled or digital controlled.

5) Special insulation design minimizing heat loss.

6) Professional designed combustion chamber, long service life,various kinds of coal are available.

7) Combustion chamber with heat exchanger together,exchanging heat among the highest temperature

parts, this latest indirect-heating technology make smoke and hot air walk their own way, absolutely

no pollution.

8) Thermal conversion reaches 80%-95%, fast warming, small volume, easy installation, reliable use.

9) Low price. The cost is only a half of the chamber boiler system.

Technical Parameter

Technical Parameters	150000Kcal	200000Kcal	250000Kcal	300000Kcal
Heat output power kcal/h	150000 kcal/h	200000 kcal/h	250000 kcal/h	300000 kcal/h
Heat efficiency ≥%	≥90%	≥90%	≥90%	≥90%
Fuel	Coal	Coal	Coal	Coal
Consumption kg/h	10-18 kg/h	15-25 kg/h	18-25 kg/h	30 kg/h
Way of adding coal	Manual	Manual	Manual	Manual
Way of control	Auto	Auto	Auto	Auto
Air flow m³/h	5000 m³/h	5500 m³/h	7000 m³/h	7000 m³/h
Temperature rise °C	80-120 °C	80-120 °C	80-120 °C	80-120 °C
Power Source V/Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz
Electric power kw	3Kw	5Kw	3Kw	5.5Kw
Diameter of air outlet mm	400mm	400mm	400mm	400mm
Weight kg	1000Kg	1500Kg	1650Kg	1700Kg
Dimension length×width×height mm	1700×900×2000	2000×1100×2200	2100×1100×2300	2100×1100×2300
Material of frame	Galvanized +spray paint	Galvanized +spray paint	Galvanized +spray paint	Galvanized +spray paint
Quality guarantee period	One year warranty lifelong service	One year warranty lifelong service	One year warranty lifelong service	One year warranty lifelong service
