Specifications
direct manufacturer with ISO 9001/2008 and BVprofessional in this line for 20 years
good quality with competitive price
Company introduction
Our company is a big direct manufacturer with a long history on this line for 20 years.As a leadingmanufacturer in china.We pay much attentions to the quality assurance and quick delivery.
welcome to visit our factory!
Anping Deming Metal Net Co.,Ltd
Tel: 86-318-7510008
steel fabric
Named building pannel
It is made of high quality low carbon steel wire with flat even surface, firm structure.
1.Specifictions:
CRB550 |
Cold-rolled ribbed steel bar |
Cold Drawn plain and Round Bar |
|
Specification |
4-12mm,larger in steps of 0.5mm |
||
|
Recommendation Specification (mm) |
4mm,5.5mm,7mm,8.5mm, 10.5mm 12mm |
4mm,5mm,6mm,7mm,8mm, 9mm,10mm,11mm 12mm |
|
Surface Condition |
With rib on Three sides |
Plain and round |
|
Production Standard |
GB13788-2002 |
BS4482:1985 |
|
Properties |
Elongation 10 08% |
Elongation 5 012% |
|
Tensile strength b 0550 Mpa |
Tensile strength b 0510 Mpa |
||
Designed strength fy0360Mpa |
Designed strength fy0320Mpa |
||
Common specifications:
wire diameter:5mm
mesh size: 50×50mm
Height×Length:1×2m
Surface treatment:Hot dipped galvanized wire before welded.
2.Features:
Steel bar grating costs less time and labor in work. It saves about 50 to 70 percent work time compared with common binding wire mesh. The use of bar grating can also strengthen the concrete parts to reduce surface breaking ratio. improve the fight against earthquakes, crack resistance.
3.Applications:
Welded steel bar panels are widely used in construction reinforcement, the ground for the tunnels, bridges, highway, airport and wharf, also in construction of wall body.
welded machine
packing and loading
in pallet or in bulk
Certifications:
For more products pls see to our website:
I am sure you will get the highest quality products at the most competitive price.
