BTO & CBT low price galvanized concertina razor barbed wire, razor barbed wire, razor wire
Introduction and application
Razor Barbed wire also called concertina Barbed wire,razor wire, is a new safety net.it is installed without clips; it runs in natural loops on walls or fencings. razor wire is costless and can be easily installed which normally used together with thefence products, such as chain link fence,welded fence,
palisade fence, razor mesh fence and etc.
Mainly used for the importance safeguard, such as the frontier defense line wire, sentry, prison, military base,railway,
highway,grass boundary.etc.
common specification:
standard:BTO-22
Crossed type
blade thickness:0.5mm
wire diameter:2.5mm
blade length:22mm
blade width:15mm,
blade spacing:34mm
standard covering length:8m
surface treatment:hot dipped galvanized plate stamping
specification list
Razor Blade Specification:
Type |
Wire Gauge (SWG) |
Barb Distance (cm) |
Barb Length (cm) |
|
Electric Galvanized Barbed Wire; Hot-dip zinc plating barbed wire |
10# x 12# |
7.5-15 |
1.5-3 |
|
12# x 12# | ||||
12# x 14# | ||||
14# x 14# | ||||
14# x 16# | ||||
16# x 16# | ||||
16# x 18# | ||||
PVC coated barbed wire; PE barbed wire |
before coating |
after coating |
7.5-15 |
1.5-3 |
1.0mm-3.5mm |
1.4mm-4.0mm |
|||
BWG11#-20# |
BWG8#-17# |
|||
SWG11#-20# |
SWG8#-17# |
|||
|
PVC PE coating thickness: 0.4mm-0.6mm; different colors or length are available at customers request. |
|||
Razor Barbed Tape Wire Specification:
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
450mm |
33 |
8M |
CBT-65 |
Single coil |
500mm |
41 |
10M |
CBT-65 |
Single coil |
700mm |
41 |
10M |
CBT-65 |
Single coil |
960mm |
53 |
13M |
CBT-65 |
Single coil |
500mm |
102 |
16M |
BTO-10.15.22 |
Cross type |
600mm |
86 |
14M |
BTO-10.15.22 |
Cross type |
700mm |
72 |
12M |
BTO-10.15.22 |
Cross type |
800mm |
64 |
10M |
BTO-10.15.22 |
Cross type |
960mm |
52 |
9M |
BTO-10.15.22 |
Cross type |
packing
Anping Deming Metal Net Co., Ltd
Established: 1992
Area: 70,000 square meter
Staff: 384
Sales Amount: 30,000,000.00 USD per year
Main Export Market: Australia, Europe, Japan, USA, South American, etc.
Main Products: Wire mesh fence, Security fence, temporary fence, barrier fence, T shape post, Y shape post and so on
Factory
Workshop
Sample room and drawing room
1. Why choose us?
Anping Deming Metal Net Co.,Ltd is a factory in Anping with a long history over 20 years. Specially in the line of wire mesh fence, we have professional workers, designers, and quality-control departments. Make sure that from materials, semi-finished product, end products, packing and loading will be ok. Also we have the ISO 9001/2008 and BV certifications, SGS and other certifications will also available is you require. We try our best to supply the highest quality product with a competitive price.
Also we are the recommended factory by our government.
2. What is our factory size.
Our factory is nearly 70,000 sqaure meters, has 380 workers. We have three welded machines, ten wire straighteners, one automatic pvc coated assembly line and one automatic pe coated assembly line.
3.How to get us?
Our factory is located in East Industrial Zone, Anping Country, Hengshui City,Hebei Provence,China. 250km away from Beijing and 130km away from Shijiazhuang.
If you want to visit us, we can pick you up at Beijing or Shijiazhuang Airport.
Free QUOTE and free sample supply, More request, please contact me for catalogue!!!
John Liu
Tel:+86-13171765007
Fax:+86-318-7510009
QQ:853742508
Skype:john.anping
