Dock Mobile Hydraulic Container Loading Ramp

Dock Mobile Hydraulic Container Loading Ramp

1)Item no:PCCR03

Loading capacity:10t

Size: 11000x2100mm

Adjustable height:1200-1800mm

G.W:3.2t

40HQ:4sets

Details

1: Hot dip galvanized steel grating connect with the ramp with bolt, and can be replaced when it is broken

2: 2 manual control cylinders,solid tire, surface painting, frame body is connected with I-steel and channel steel

2)Item no:PCCR04

Steel grating can be replaced

Loading capacity:10t

Size: 11000x2200mm

Adjustable height:1200-1800mm

G.W:3.2t

40HQ:4sets

Details

1: Hot dip galvanized steel grating connect with the ramp with bolt, and can be replaced when it is broken

2: 2 manual control cylinders,solid tire, surface painting, frame body is connected with I-steel and channel steel

3. Mobile dock leveler is accessory equipment helping forklift or hand trailer to moving goods into the carriages or containers directly. It adopts handle hydraulic equipment to adjust the lifting height to truck height, or changed to electricity power. And the ramp can be operated by single person easily, in this way saving people work and promoting work efficiency.
The regular model of this ramp is: width-2.08m, length-11m, adjusting height range-1m to 1.7m. And it also can be designed and produced according to customers’ requirements.
This machine is suit for: often material handling, warehouse, wharf, logistics center working place.
