Galvanized Screw Steel Plate Helix Ground Anchor
US$ 1 - 10
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Adm
Model Number:
ADMGA 0454
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shandong, China
Brand Name
Adm
Model Number
ADMGA 0454
Type
Pole Anchor
Material
Iron
Diameter
1CM
Length
66''
Capacity
200KGS
Standard
ISO
Galvanized screw steel plate helix ground anchor
Description of ground anchor
Size:8 8" helix 66"long *1''diameter
Material:steel
Surface treatment:hot dip galvanized
Weight:8.6kg
Package way: pallet
Features:
- An integral forged eye anchor with a helix welded to the shaft and for manual or machine.
- Manual installations accomplished by inserting a bar through the eye and screwing the anchor down in line with the guy.
- Installation with portable or vehicle mounted installing equipment is accomplished with adapters.
-
Name Item No Specification Length Head Weight(kg) Single ground anchor 4150 5/8 X 5 1524mm 62.23mm 2.8 4151 5/8 X 6 1828mm 3.3 4152 5/8 X 7 2134mm 3.8 4153 5/8 X 8 2438mm 4.3 4154 3/4 X 7 2134mm 73.03mm 5.4 4155 3/4 X 8 2438mm 6.1 4156 3/4 X 10 3048mm 8 Double ground anchor 4165 5/8 X 6 1828mm 64mm 3.4 4166 5/8 X 7 2134mm 3.9 4167 5/8 X 8 2438mm 4.4 4168 3/4 X6 1828mm 69mm 4.7 4169 3/4 X 7 2134mm 5.4 4170 3/4 X 8 2438mm 6.1 4171 3/4 X 9 2743mm 6.8 4172 3/4 X 10 3048mm 8 4173 1 X 8 2438mm 83mm 11 4174 1 X 10 3048mm 13 Three ground anchor 4180 3/4 X 8 2438mm 84mm 6.1 4181 3/4 X 9 2743mm 6.9 4182 1 X 8 2438mm 104mm 10.4 4183 1 X 10 3048mm 12.8 4184 1-1/4 X 10 3048mm 110mm 21.5
Helix Size (Inches) |
Rod Diameter |
Rod Length (Inches) |
Weight Ea (lbs) |
4 |
3/4 |
54 |
8.1 |
6 |
3/4 |
66 |
10.9 |
8 |
1 |
66 |
19.1 |
10 |
1-1/4 |
66 |
30.3 |
10 |
1-1/4 |
96 |
41.1 |
15 |
1-1/4 |
96 |
52.0 |
