drinkers/red poultry feeders/plastic poultry feeders and drinkers

1. Drink system adopts advanced nipple automatic drinking system with no leakage to keep the poultry house dry, and to reduce the risk of disease infection.

2. It includes medicator, nipple, water cup, pipes, complete and drainage, water pressure adjuster.

3. Drinkers can be triggered from 360 degree which helps young chicken start well and makes drinking easier.

4.  All the metal parts are hot galvanized for rust prevention.

5. Provide the right amount of water for their climate and house conditions.

6. This chicken nipple drinker is specially designed to meet the requirement for automatic chicken water line, providing proper water flow and hygienical watering environment.

7. Provide the right amount of water.

8. The single-arm water receiving cup with a rational structure is more suitable for new design idea.

9. Made up of best plastic, so it is light in weight and long life span in usage.

10. Save water , convenient to dismantle and use.

11. Keep the water from dropping onto the floor, so it can be dry.

12. Anti-corrosive, long durability.

13. Easy maintenance and operation.

  poultry  cage chicken   feeding  system  System

1. High-quality special driving reduction motor.

  Power: 0.75kw,  Voltage:380V   Frequency: 50HZ, Three-phase

2. V-shaped Bin ( with Hopper)

   Bin Volume: 115L,  Hopper volume: 38L

   Material: Hot-DIP galvanized sheet

3. Feeding system

   Diameter of conveying pip:  45mm

   Material: Hot-DIP galvanized steel pipe with the zinc coating amount of   more than 275 g/m2

   Helical spring auger from South Africa, feeding capacity: 450kg/h.

4. Material level sensor from Germany: Time delay range 0 to 2 hours.

Chicken layer cage:

 Material :  Galvanized wire made from low carbon steel & hot dip galvanized o& PVC coated
