Galvanized Battery Hen Houses for 96 /120 Chicken
Specifications
1.galvanized or PVC coated batterty hen houses2. 3-6 tiers hen houses
3.Length: 1.88m ,2m or 2.15m
4.96-200 hens/house
galvanized battery Hen Houses for 96/120 chicken
1.Application: Poultry chicken cages, poultry layer chickens, broiler chickens, baby chick from day old until laying eggs
2.chicken cages surface treatment :
- electro galvanized (also named cold galvanized), Using the electrolysis,during the process will form a layer uniformity and good combination metal or alloy sedimentary that covering the metal wire cages, Surface zinc coated is thin, can rach about 10-20g/m2,easy to get rust. but the sureface is smooth and cost lower.
- hot dip galvanized: make the solid zinc melting into liquid, then put the derusting metal cages into the 500°c melting liquid zinc, then the metal cage sureface will attach the zinc. Surface zinc coated is thick, can rach about 500g/m2,hard to get rust. but the sureface is not smooth.
- PVC coated : Can be coated into any color as you like
3.Specifications of the chicken cage
- 3 layers chicken cage:
1.88m
|
Wire Diameter: 2.4 and 2.9mm Size of cage : 1.88m * 60cm *(37cm*32cm) Nest size:47cm *38cm*(37cm*32) width of cage frame:2.2m,vertical height:1.4m |
1).3 tiers on each side( total 2 sides) of the frame 2). 8 Nests on each tiers,total 24 nests one set 3).4 chicken per nest 4).96 chicken per set |
2.15m
|
Wire Dia 2.5 and 3.0mm Size of cage : 2.15m *60cm *(37cm*32cm) Nest size:43cm*38cm*(37cm*32cm) Cage frame width:2.2m, vertical height:1.4m |
1)3 tiers on each side(total 2 sides) of the frame 2). 10 nests on each tier,total 30 nests 3).4chicken per nest 4).120chicken per set |
- 4 Layers chicken cage
- 1.88m
|
Wire Diameter: 2.4 and 2.9mm Size of cage : 1.88m * 60cm *(37cm*32cm) Nest size:47cm *38cm*(37cm*32) width of cage frame:2.4m,vertical height:1.8m |
1).4 tiers on each side( total 2 sides) of the frame 2). 10 Nests on each tiers,total 32 nests one set 3).4 chicken per nest 4).128chicken per set |
2.15m
|
Wire Dia 2.5 and 3.0mm Size of cage : 2.15m *60cm *(37cm*32cm) Nest size:0.43m *0.4m*(0.38m*0.32m) Cage frame width: 2.4m, vertical height: 1.8m |
1).4 tiers on each side(total 2 sides) of the frame 2) 10 nests on each tier,total 40 nests one set 3).4chicken per nest 4).160 chicken per set |
4. Each cage accessories: drinking water, feeding trough, cage frame, PVC pipe, clip, each row cage
has 3-6 water tank.
Anping County Innaer Wire Mesh Manufacturing Co., Ltd.
Anping County Innaer Wire Mesh Manufacturing Co., Ltd. is compose of “Innaer poultry cages factory”,“ Innaer metal wire mesh factory”, “Innaer welded wire mesh factory ”,“ Innaer fence factory”, four branch factories, Factory founded in 1990, having its own right to produce and sale all kinds of poultry cages, metal mesh , wire ,mechanical equipment,import and export enterprise.
chicken laying cage container loading
our products have been exported to the Southeast Asia, Middle East, Europe, Africa etc regions.,and with Malaysia, Singapore, Japan, the United States, Germany, Brazil, Nigeria, Pakistan, dubai etc countries signed a long-term contract of sale.
customers' visit
Even when you don't have the time and energy to visit our factory, these customers come to visit our factory pictures, hope you can more trust to us.
Thank you for your patience .If you are interested in our products or there is any question about our products, please contact us freely. I am Emily zhang and hope to cooperate with you. Welcome to visit our factory!
