Concertina Razor Wire with pallet widely used in high-grade residence district
Concertina Razor Wire is a hot product in high-grade residence district.The concertina coil's sharp blade canmake a threat to the people who are trying to going into the district uninvitely. The Blade wire is very esay to install and can save a lot of people work.
Shape: BTO10 BTO-22 BTO-30 CBT-60 CBT65
Surface treatment: PVC; Electro or Hot dipped galvanized
Material: Steel or stainless Steel(430; 304, 316, 316L)
| Barbed Tape Wire Specification | ||||
| Outside Diameter | No.of Loops | Standard Length per Coil | Type | Notes |
| 300mm | 33 | 4-5m | CBT-60.65 | Single coil |
| 450mm | 33 | 7-8m | CBT-60.65 | Single coil |
| 500mm | 56 |
12-13m | CBT-60.65 | Single coil |
700mm |
56 | 13-14m | CBT-60.65 | Single coil |
| 960mm | 56 | 14-15m | CBT-60.65 | Single coil |
| 450mm | 56 | 8-9m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 500mm | 56 | 9-10m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 10-11m(3 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 700mm | 56 | 10-12m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 900mm | 56 | 12-14m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| 980mm | 56 | 14-16m(5 clips) | BTO-10.12.18.22.28.30 | Cross type |
| Razor blade type and specification | |||||
| Reference Number |
Thickness (mm) |
Wire Dia (mm) |
Barb Length (mm) |
Barb Width (mm) |
Barb spacing (mm) |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-15 | 0.5±0.05 | 2.5±0.1 | 15±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-30 | 0.5±0.05 | 2.5±0.1 | 30±1 | 18±1 | 45±1 |
| CBT-25 | 0.5±0.05 | 2.5±0.1 | 25±1 | 16±1 | 40±1 |
| CBT-60 | 0.5±0.05 | 2.5±0.1 | 60±1 | 32±1 | 100±1 |
| CBT-65 | 0.5±0.05 | 2.5±0.1 | 65±1 | 21±1 | 100±1 |
We can also manufacture the Barbed wire for you
Barbed wire weave types:
1) Single strand barbed wire,
2) Double strand double twisted barbed wire;
3) Double strand common twisted barbed wire
1.Material:
High quality low carbon steel wire,stainless steel wire ,medium carbon steel wire(galvanized,plastic coated, plastic sprayed)
2.Type:
Double twisted barbed wire ,general barbed wire,single strand barbed wire.PVC barbed wire,stoving varnish barbed wire.
3.Performance and characteristic:
By twisting and weaving,firm and beautiful.
4.Features:
Galvanized barbed wire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts.
5.Application:
Barbed wire can be widely used as accessories for woven wires fences to form a fencing system or security system. It is called barbed wire fences or barbed obstacles when it is used simply by itself along the wall or the building to give a kind of protection. Barbed wire is also written as barbed tape as it is always used in a line to form a kind of tape
Delivery Detail: 7-15 days for a 20' or 40'HC after confirmation
Anping Haotian Hardware Wire Mesh Product Company
1.Our products have passed ISO9001,SGS,IAF,CE certifications.
2.We also attended the world famous fair every year.
3.We have Quality Assurance staff to confirm the quality in the factory:
We agreed to clients to invite third party to check the quality of our products.
Our service
1.Sample policy:A piece of sample is free.Pls kindly tell us your express account &address in detail.After you given the order, we will return the sample fee to you.2. Customer size can be acceptable.
3.Drawing are available.
4.If you have any questions, pls contact:
Katherine Tian
Skype:katherine.tian1989
M:0086-187-328-75975
E:903532541(AT)qq(dot)com
FAQ
Please note the delivery time and the package,and the loading quanties.Please confirm before order or delivery
