Electro Galvanized/stainless Steel Concertina Razor Wire Available
US$ 30.459 - 30.459
MOQ: 10 Tons
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
haotian
Model Number:
ht7-1016
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Galvanzied Crossed Razor Wire/concertina CoilsUS$ 900 - 1,030MOQ: 10 Tons -
Concertina Razor Wire Frightening and Stopping to the Aggressive Perimeter IntruderUS$ 800 - 1,350MOQ: 10 Tons
-
Concertina Razor Wire Used as Fence for CottageUS$ 800 - 1,350MOQ: 10 Tons
-
Concertina Razor Wire Strip Galvanized to Prevent CorrosionUS$ 712 - 1,300MOQ: 10 Tons
-
Galvanized Barbed Iron Wire/Suitable for Agriculture/Animal Husbandry Industry/ Dwelling HouseUS$ 700 - 1,200MOQ: 10 Tons
Place of Origin
Hebei, China
Brand Name
haotian
Model Number
ht7-1016
Material
Iron Wire
Surface Treatment
PVC Coated
Type
Other, Barbed Wire Mesh, BTO-12 BTO-18 BTO-22 CBT-60 CBT-65
Razor Type
Single Razor
Specifications
electro galvanized/stainless steel Concertina Razor Wirehot dipped galvanzied concertina coil Length:10-65mm
spacing: 26mm
Concertina Razor Wire electro galvanized/stainless steel available
Product Description
Concertina Razor Wire, Razor Barbed Wire, Razor Wire
Shape: BTO10 BTO-22 BTO-30 CBT-60 CBT65
Surface treatment: PVC; Electro or Hot dipped galvanized
Material: Steel or stainless Steel(430; 304, 316, 316L)
Packaging Detail: Plastic film inside and outside weaving bag, or use carton box, using pallet or according to customer requirments
Delivery Detail: 7-15 days for a 20' or 40'HC after confirmation
Razor wire is also named concertina coils or razor type barbed wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With beautiful and sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
Razor type barbed wire is widely used in high-grade residence district, warehouses, prisons and in military fields and other sites requiring severe fencing and security. Razor wire can be classified into straight type razor wire, concertina coils, crossed type and flat type according to the installation models.
Shape: BTO10 BTO-22 BTO-30 CBT-60 CBT65
Surface treatment: PVC; Electro or Hot dipped galvanized
Material: Steel or stainless Steel(430; 304, 316, 316L)
Packaging Detail: Plastic film inside and outside weaving bag, or use carton box, using pallet or according to customer requirments
Delivery Detail: 7-15 days for a 20' or 40'HC after confirmation
Razor wire is also named concertina coils or razor type barbed wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With beautiful and sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
Razor type barbed wire is widely used in high-grade residence district, warehouses, prisons and in military fields and other sites requiring severe fencing and security. Razor wire can be classified into straight type razor wire, concertina coils, crossed type and flat type according to the installation models.
| Razor Blade Type and Specification |
| Reference Number | Thickness | Wire Diameter | Barb Length | Barb Width | Barb Spacing |
| BTO-10 | 0.5 ± 0.05 | 2.5 ± 0.1 | 10 ± 1 | 13 ± 1 | 26 ± 1 |
| BTO-12 | 0.5 ± 0.05 | 2.5 ± 0.1 | 12 ± 1 | 15 ± 1 | 26 ± 1 |
| BTO-18 | 0.5 ± 0.05 | 2.5 ± 0.1 | 18 ± 1 | 15 ± 1 | 33 ± 1 |
| BTO-22 | 0.5 ± 0.05 | 2.5 ± 0.1 | 22 ± 1 | 15 ± 1 | 34 ± 1 |
| BTO-28 | 0.5 ± 0.05 | 2.5 ± 0.1 | 28 ± 1 | 15 ± 1 | 45 ± 1 |
| BTO-30 | 0.5 ± 0.05 | 2.5 ± 0.1 | 30 ± 1 | 18 ± 1 | 45 ± 1 |
| Outer diameter | No. of loops | Standard length per coil | Type | Notes |
| 450mm | 33 | 7m-8m | CBT-65 | Single coil |
| 500mm | 41 | 10m | CBT-65 | Single coil |
| 700mm | 41 | 10m | CBT-65 | Single coil |
| 960mm | 54 | 11m-15m | CBT-65 | Single coil |
| 500mm | 102 | 15m-18m | BTO-12,18,22,28,30 | Cross type |
| 600mm | 86 | 13m-16m | BTO-12,18,22,28,30 | Cross type |
| 700mm | 72 | 12m-15m | BTO-12,18,22,28,30 | Cross type |
| 800mm | 64 | 13m-15m | BTO-12,18,22,28,30 | Cross type |
| 960mm | 52 | 12m-15m | BTO-12,18,22,28,30 |
Cross type |
Packaging & Shipping
Bluk, Pallet or Carton or according to CUSTOMER'S REQUEST.
