CBT 65 Razor Wire Factory Hot Dipped Galvanzied Razor Wire Fencing Military Concertina Wire
US$ 799 - 1,500
MOQ: 10 Tons
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
haotian
Model Number:
ht7-503
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Heavy Zinc Coated Razor Wire PhilippinesUS$ 900 - 1,300MOQ: 1 Roll -
Electric Galvanized/Hot-dipped Galvanized Razor Wire for Security UseUS$ 800 - 1,300MOQ: 5 Tons
-
Single Strand Razor Barbed Wire Net Snake Abdominal Type With High Tensile StrengthUS$ 10.86 - 30.85MOQ: 100 Rolls
-
2 Strands Iowa Type Barbed Wire Barb Wire Accessory Barbed Wire Price per RollUS$ 10.91 - 26.82MOQ: 100 Rolls
-
Galvanized Concertina Razor Barbed Wire Used as Fence for Cottage and Society FenceUS$ 10.247 - 20.36MOQ: 100 Rolls
Place of Origin
Hebei, China
Brand Name
haotian
Model Number
ht7-503
Material
Iron Wire
Surface Treatment
PVC Coated
Type
Barbed Wire Mesh
Razor Type
Single Razor
Specifications
CBT 65 razor wire factory hot dipped galvanzied razor wire fencing military concertina wireProtection of Garden Appartment
CBT 65 razor wire factory hot dipped galvanzied razor wire fencing military concertina wire
Product Description
1.Razor barbed wire fence is mainly used in the key project, which and razor wire concertina are the majority of our products. Razor barbed wire fence is general made of stainless steel blade or galvanized steel blade. Two pieces of stainless steel razor wire or zinc-coated razor wire can be bounded together by clips to make it stronger. The fence is mainly composed of very sharp points and arranged at intervals along the strands with beautiful outlook and practical property.
The razor wire fence adopts galvanized raw material will have a long service life. Besides, it has stainless steel blade and other materials.
2.Features: Compact and rational structure, high safety factor, for the protection of prison and key project.
Technical Note: Razor barbed wire fence can be made according to the actual dimension of customer; the special specification is manufactured according to the drawing.
3.Applications: Razor wire fencing is widely used in government agencies, prisons, and military areas, etc. Especially in prisons, the unique structure of sharp blades. It often can be used with barbed wire togeher installed on the top of chain link fence and palisade fence for high security.
| Razor Blade Type and Specification |
| Reference Number | Thickness | Wire Diameter | Barb Length | Barb Width | Barb Spacing |
| BTO-10 | 0.5 ± 0.05 | 2.5 ± 0.1 | 10 ± 1 | 13 ± 1 | 26 ± 1 |
| BTO-12 | 0.5 ± 0.05 | 2.5 ± 0.1 | 12 ± 1 | 15 ± 1 | 26 ± 1 |
| BTO-18 | 0.5 ± 0.05 | 2.5 ± 0.1 | 18 ± 1 | 15 ± 1 | 33 ± 1 |
| BTO-22 | 0.5 ± 0.05 | 2.5 ± 0.1 | 22 ± 1 | 15 ± 1 | 34 ± 1 |
| BTO-28 | 0.5 ± 0.05 | 2.5 ± 0.1 | 28 ± 1 | 15 ± 1 | 45 ± 1 |
| BTO-30 | 0.5 ± 0.05 | 2.5 ± 0.1 | 30 ± 1 | 18 ± 1 | 45 ± 1 |
| Outer diameter | No. of loops | Standard length per coil | Type | Notes |
| 450mm | 33 | 7m-8m | CBT-65 | Single coil |
| 500mm | 41 | 10m | CBT-65 | Single coil |
| 700mm | 41 | 10m | CBT-65 | Single coil |
| 960mm | 54 | 11m-15m | CBT-65 | Single coil |
| 500mm | 102 | 15m-18m | BTO-12,18,22,28,30 | Cross type |
| 600mm | 86 | 13m-16m | BTO-12,18,22,28,30 | Cross type |
| 700mm | 72 | 12m-15m | BTO-12,18,22,28,30 | Cross type |
| 800mm | 64 | 13m-15m | BTO-12,18,22,28,30 | Cross type |
| 960mm | 52 | 12m-15m | BTO-12,18,22,28,30 | Cross type |
4. razor barbed wire
5.popular size:
Standard wire dia: 2.5mm
Thickness: 0.5mm, 0.6mm
Barbed spacing: 26mm-100mm
Barbed length: 9mm-67mm
Barbed width: 15mm-21mm
Standard length per coil: 8m-16m, 7-18m
Outside diameter: 450mm-960mm
Number of loops (turns): 33-102
Packaging & Shipping
Company Information
Haotian Hardware Wire Mesh Company Advantage :
1.Our products have passed ISO9001,SGS,IAF,CE certifications.
2.We also attended the world famous fair every year.
3.We have Quality Assurance staff to confirm the quality in the factory:
We agreed to clients to invite third party to check the quality of our products.
Contact info.
Our Services
1.Sample policy:A piece of sample is free.Pls kindly tell us your express account &address in detail.After you given the order, we will return the sample fee to you.
- 2. Customer size can be acceptable.
3.Drawing are available.
4.If you have any questions, pls contact:
