Mineral fiber ceiling boardund absorption
2.fire/moisture proof
3.size:(300~600)x(600~2400mm)x(12~20mm)
4.low densi
Product: Acoustic Mineral fiber ceiling board
Standard sizes:600mmx600mm/600x1200mm
24"x24"/24"x48"
Other sizes: (300-450mm)x(1200mm-2400mm)x(15mm-20mm)
(12"-16")x(48"-96")x(3/5"-4/5")
Edge detail: Angled Tegular
Beveled Tegular
Suqare Lay-in
Normal Concealed and exceed concealed
Surface pattern:Different designs avaliable.
Physical data
1.Raw materials:Wet-formed mineral fiber
2.Surface finish:Factory-applied vinyl latex paint
3.Fire performance :China B1 grade(meet GB8624-1997)
4.Density:3.50kg/m2 ---4.50kg/ m2 up to thickness,180kg-230kg/m3.
5.Content of Recycled material:45%~55%
6.NRC(Noise reduction coefficient): 0.55
7.CAC(ceiling attenuation class): 35
8.Light Reflectivity: Minimum 0.85
Feature
1.High light-reflectance
2.nondirectional pattern designed ,easy installation
3.Fire-resistance
4.Adopt high quality mineral wool,100% asbestos-free
5.light-weight and easy to be cut.
6.Withstand condition with relative humidity up to 99%.
7.Excellent sound absorption ability and competitive price.
8.Excellent ability of sag-resistance
Installation: When the building is dry enough and chemical gas disappears ,installation can be started.Make sure the temperature doesnt exceed 490 C and relative humility not exceed 99%.
Transportation and storage:When transporting,take care of the edge of the board.It will be better to lay the panels on dry backing-plate horizontally,about one meter away from the wall.
