20MM PE100 Polyethylene Nature Gas Pipe Hot Sales
1.HDPE pipe 20mm - 630mm
2.En 2.3mm-57.3mm
3.High quality and cheap price
ISO/CE/BV
Product introduction
brand: SINODIAMOND
specification:20-630mm
material: high density polyethylene
length: 4m,6m or as request
color: black with yellow line or as request
standard: ISO14001,ISO9001,GB/T15558.1-2003 ,GB/T15558.2-2005
pressure grade: 1.0Mpa, 1.6Mpa
wall thickness: SDR17.6,SDR11
packing: straight pipe or coil pipe
connection: socket fusion, butt fusion, electro-fusion, flanged
Applications:
Transportation for neutral gas, liquefied petroleum gas, coal gas and industrial corrosive liquid.
Features
1. Good corrosion resistance
2. Excellent flexibility
3. Good abrasion resistance
4. Good stress crack resistance
5. Long usage life of 50 years
6. Large flow capacity
7. Remarkable economic benefits
8. Convenient construction
PE gas pipe specification catalog | |||||
outside diameter mm | PE80 | PE100 |
| ||
SDR17.6/0.2MPa | SDR11/0.4MPa | SDR17.6/0.6MPa | SDR11/1.0MPa |
| |
wall thickness mm | wall thickness mm | wall thickness mm | wall thickness mm |
| |
mm | mm | mm | mm |
| |
16 | 2.3 | 3.0 | 2.3 | 3.0 |
|
20 | 2.3 | 3.0 | 2.3 | 3.0 |
|
25 | 2.3 | 3.0 | 2.3 | 3.0 |
|
32 | 2.3 | 3.0 | 2.3 | 3.0 |
|
40 | 2.3 | 3.7 | 2.3 | 3.7 |
|
50 | 2.9 | 4.6 | 2.9 | 4.6 |
|
63 | 3.6 | 5.8 | 3.6 | 5.8 |
|
75 | 4.3 | 6.8 | 4.3 | 6.8 |
|
90 | 5.2 | 8.2 | 5.2 | 8.2 |
|
110 | 6.3 | 10.0 | 6.3 | 10.0 |
|
125 | 7.1 | 11.4 | 7.1 | 11.4 |
|
140 | 8.0 | 12.7 | 8.0 | 12.7 |
|
160 | 9.1 | 14.6 | 9.1 | 14.6 |
|
180 | 10.3 | 16.4 | 10.3 | 16.4 |
|
200 | 11.4 | 18.2 | 11.4 | 18.2 |
|
225 | 12.8 | 20.5 | 12.8 | 20.5 |
|
250 | 14.2 | 22.7 | 14.2 | 22.7 |
|
280 | 15.9 | 25.4 | 15.9 | 25.4 |
|
315 | 17.9 | 28.6 | 17.9 | 28.6 |
|
355 | 20.2 | 32.3 | 20.2 | 32.3 |
|
400 | 22.8 | 36.4 | 22.8 | 36.4 |
|
450 | 25.6 | 40.9 | 25.6 | 40.9 |
|
500 | 28.4 | 45.5 | 28.4 | 45.5 |
|
560 | 31.9 | 50.9 | 31.9 | 50.9 |
|
630 | 35.8 | 57.3 | 35.8 | 57.3 |
|
