Galfan welded wire mesh reinforce 100x200x30cm Germany gabions

 1.Wire Mesh Gabion Box Stone Cages description

(1) Introduction: Gabions are free-draining walls constructed by filling large baskets with broken stone.

(2)Types:  The baskets are made from galvanised steel mesh, woven strips, or plastic mesh.

(3)Merits:  The permeability and flexibility of gabions make them suitable where the retained material is likely to be saturated and where the bearing quality of the soil is poor.

2.Wire Mesh Gabion Box Stone Cages material

(1) Electro  Galvanized steel wire: diameter 2.0mm-4.0mm, tensile strength >380Mpa, zinc:10g / m2.

(2) Hot Galvanized steel wire: diameter 2.0mm-4.0mm, tensile strength >380Mpa, zinc:300g / m2.

(3) Galfan: Zinc 5% Aluminum ,  Zinc 10% Aluminum- wire diameter 1.0mm-3.0mm, tensile strength >380Mpa.

(4) Coated galvanized steel wire: low carbon steel wire, pvc coated.

3Wire Mesh Gabion Box Stone Cages wire diameter:

     Core wire : 2-4mm

     Edge wire: thicker 0.5-1.0mm than mesh diameter.

     Binding wire: 2-2.2mm

4.Wire Mesh Gabion Box Stone Cages sizes:

      2m x 1m x 1m,3m x 1m x 1m,4m x 1m x 1m,2m x 1m x 0.5m,4m x 1m x 0.5m, (with partition ) and Custom orders available.

5.Wire Mesh Gabion Box Stone Cages  Hole size:

      60 x 80mm, 80 x 100mm, 80 x 120mm, 100 x 120mm, 120 x 150mm.

6.Wire Mesh Gabion Box Stone Cages specification:

  7.Wire Mesh Gabion Box Stone Cages process

    wire drawing---galvanized--- galvanized after weaving or galvanized before weaving.

 8.Wire Mesh Gabion Box Stone Cages application

(1).Gabion wire mesh is used for slope and foundation pit support ,

( 2).Prevention or rock breaking ,slope planting ,

( 3).Water and soil protection,

( 4).High mesh fence,protection of dam and seawall against erosion ,etc.

 9.Wire Mesh Gabion Box Stone Cages packaging

     50-100 gabion wire mesh /per bundle,wrapped with 2 to steel strips
