LX-2008C6D Lanstar alloy wire electric fence greater protection range energizer

Specifications

larger range energizer
The electric fence energizer with the front fence which establishes a physical &psy

Welcome to Lanstar Co., LTD

LX-2008C6D Lanstar alloy wire electric fence greater protection range energizer

1.Differential voltage output technology: every wire has voltage, have the differential voltage between the two adjacent wires.

2.LCD or LED indicate the working state and the voltage on every wire of fence.

3.High/low voltage switch manually, long-distance equipment auto switch function.

4.Short circuit, break and tamper alarm, Self-inspection System for equipment fault

5.Waterproof casing and downward appearance design leading the industry development.

6.RS 485 bus control, keypad, computer, network and multiple long distance management solution.

7.DC12V, NC/NO dry contact alarm output, can work with other modern security products

8.Lanstar electric fence energizer forperimeter security  with CE,ISO certificate

9. 6-wire fence system greater protection range

LX-2008C6D Lanstar alloy wire electric fence greater protection range energizer

Exihibition pictures:

Certificate



Technique specification:

1.Power supply	AC180V-240V 50Hz
2.System power consumption	10 Watt
3.Operating environment	Temperature:-40 to +50°C
4.Relative humidity	≤95%
5.Output peak voltage	5KV~10KV
6.Output low voltage	700~1000V
7.Peak current of pulse	<10A
8.Pulse duration	≤0.1s
9.pulse interval time	1s
10.Max quantity of electricity of pulse	2.5mC
11.Max energy of pulse	≤5.0J



Packing details:

Demension	410×320×220 (mm)
Net Weight	4.2kg  (Without battery)
Color	Blue
Packaging Details	Carton package







1.Sample order acceptable



2.Customized logo with OEM service is available for bulk order



3.Warranty:3 years(except artificial damage and  vis major)



4. Considerate service after sale





What is electric fence system?

Electric fence system(the electric fence energizer and front fence ) is a psychological and physical

barrier to detect,deter and delay intruders or wild animals with non-lethal high voltage pulse,which is widely used in farming and security areas.



Why choose us?

• Years of experience in electric fencing field
• Professional staffs for providing different solutions
• High Quality products and competitive prices
• Factory warranty with CE certificate and ISO9001:2008 certificate

LX-2008C6D Lanstar alloy wire electric fence greater protection range energizer
