Two post 4.5t auto lifter

Specifications

Lifting capacity:4500kg
Post Height: 3602mm
Car max lifting height: 1876mm
Minimumheight: 76mm
Clearance between posts: 2779

Specification of our  auto lifter



Lifting capacity:4500kg
Post Height: 3602mm
Car max lifting height: 1876mm
Minimumheight: 76mm
Clearance between posts: 2779.5mm
Total width: 3339.5mm
Width of post material:180mm
armmaximumlength:1362.7
armminimumlength: 728.7
Lifting Time: 50s
Lowering Time: 30s
Power Supply Voltage: 220V/380V ,1ph/3ph
Net Weight:565kg Gross Weight :625kg
Packing Dimension:
860*290*360mmand 3705*740*515
Cubic Meter: 1.5cbm
Shipping: 12 SETS / 20’ container

Advantages of our car  lifts:
1,Column is made of the original steel plate, no deformation during usage
2,Electrostatic powder coating .which is corrosion-resistant.
3,Slipway and arm protection added.
4,The lowest height of the tray is only from 110-120mm, which is suitable to all car types.
5,anti-explosion oil cylinder valve
6,Hydraulic power unit is CE certificated.
1) manual adjustable overflow valve to adjust the pressure
2) manual adjustable throttle to adjust slipway speed
7, Italy "Aston" Oil seal which could use for 8-10 years.
8,Lifting capacity: Maximumlifting weight is1.2 times of ratting weight .Ultimate lift weight is 1.6
times of rating weight.
