Specifications
Press oil machine can press sesame, walnut kernel, peanut, pine seed (better to get rid of the shell), almond, spricot kernel...Press oil machine can be used for process many kinds of raw material: sesame, walnut kernel, peanut, pine seed (better to get rid of the shell), almond, spricot kernel, perilla, linseed and other oil crops.
Structure:
This machine mainly includes three parts:
1. main engine 2. hydraulic system 3.electrical system
The following is the specific introduction:
1. main engine:
Main engine includes base,upright,top plate,oil drip pan,nut and etc which is one of the main parts. When the oil material is put into the assemly of the press boring,then it being drived up by the oil cylinder piston ,oil will be outflow from the gap of press boring,and then pass the oil drip pan to the drum for oil storage.
materials |
models |
time period/time |
weight/time |
output /10 hour |
oil ratio |
|
sesame |
type 180 |
5-8 minutes |
1-3kg |
150-300kg |
42%--52% |
type 230 |
4-6minutes |
2-7.5kg |
450-750kg |
||
type 320 |
8-10minutes |
5-15kg |
800-1200kg |
||
|
almond |
type 180 |
5-8 minutes |
1-2.5kg |
150-250kg |
40%-45% |
type 230 |
4-6minutes |
2-6kg |
350-500kg |
||
type 320 |
8-10minutes |
5-14kg |
700-1000kg |
||
|
walnut meat
|
type 180 |
5-8 minutes |
1-2.5kg |
150-250kg |
50%-60% |
type 230 |
4-6minutes |
2-6kg |
350-500kg |
||
type 320 |
8-10minutes |
5-14kg |
700-1000kg |
||
|
pine nut |
type 180 |
5-8 minutes |
1-2.5kg |
150-250kg |
45%-60% |
type 230 |
4-6minutes |
2-7kg |
350-500kg |
||
type 320 |
8-10minutes |
5-14kg |
700-1000kg |
1 |
Models
|
6YZ-180 |
6YZ-230 |
6YZ-320 |
2 |
External Dimension(mm) |
800*650*1100 |
900*750*1400 |
1100*1000*1500 |
3 |
Weight of machine |
530kg |
880kg |
1320kg |
4 |
Nominal pressure |
1600KN |
2200KN |
3000KN |
5 |
Max pressure for working |
55Mpa |
55Mpa |
55Mpa |
6 |
Power of electricity heating circle |
1KW |
1KW |
2KW |
7 |
Controlling temperature of heating circle |
70-100°C |
70-100°C |
70-100°C |
8 |
Sesame weight/time |
1-3kg |
2-7kg |
5-15kg |
9 |
Motor types and power (kw) |
Y901-4-1.5kw |
Y901-4-1.5kw |
Y901-4-1.5kw |
