Screw Plate-shaped Chipping Machine -wood Chipper

Screw Plate-shaped Chipping Machine -wood Chipper photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Wood Chipper
Use:
wood chipping machine
Power Type:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Type Wood Chipper
Use wood chipping machine
Power Type Electric
Production Capacity higher
Place of Origin Henan, China
Brand Name China Dafu
Model Number 600model
Certification ISO9001:2000,CE
Warranty 1

Specifications

Screw plate-shaped chipping machine can cut log and small-diameter log with less than 200mm diameter

Introduction of Disk Wood Chipping Machine :

Screw plate-shaped chipping machine can cut log and small-diameter log with less than 200mm diameter and is applicable to paper pulp factory, forest tree factory, paper mill, thermal power plant, etc. Wood Chipping machine is mainly composed of four parts such as principal machine, coupling, bottom frame and motor, etc, in which the principal machine of chipping machine is composed of cutter head, upper and lower covers, feed inlet and outlet, etc.

Specifications of Disk Wood Chipping Machine

Mobel of machine

2L×640

2L×1000

Diameter of cutter head(mm)

640

1000

Rotary speed of cutter head(r/min)

970

740

Quantity(sheet) of fly cutter

6

6

Length of wood chip,thickness(mm)

15-35 2-3

15-35 3-7

Mode of feeding

Declination

Declination

Dimension of feeding opening(mm)

150×140

250×250

Productive Capacity (t/h)

3-5

5-8

Power of electric motor(kw)

37

75

Maximum diameter of cutting wood(mm)

100

200

Mode of discharging

Up

Up

Weight of complete machine (kg)

1192

3375

External dimension (length×width×height)

2002×1175×1360

2820×1838×1892
