Specifications
gypsum powder production machine1.first grind, second bake
2.high production capacity
3.high purity
With the development of gypsum industry, there is a large demand for quantity and high quality of gypsum powder. Therefore, the high level of gypsum powder production technology is required. In the process of gypsum powder production, drying and dewatering is the key link, which is also the most difficult one to control. In order to solve this problem, we develop a new type of drying and dewatering equipment---ebullience calciner, which is produced based on the exploring of the gypsum production filed. Following is the brief introduction of the gypsum production technology and ebullience calciner working principle.
New-type gypsum frying boiler- ebullience calciner
First grind and second bake. The largest advantage of this technique, compared with that of “first grind and second bake”, is energy consumption reduction. Large plaster stone shall be ground into powders with diameter less than 0.2mm, which increases the specific surface when calcining, enlarges the contact area with heat medium, improves calcination heat exchange efficiency and lowers energy consumption greatly. This equipment has small bulk, large production capacity, and simple structure and is hard to destroy.
The equipment configuration table fluidized furnace
|
Daily output (T) |
Volume of fluidized furnace (M) |
Roots blower (KW) |
Electrostatic precipitation ( |
Thermal conductivity oil furnace |
Auxiliary equipment |
note |
150 |
1.3 |
11 |
4 |
200 |
Hoist, root blower, feeder conveyor, frame body |
|
200 |
1.4 |
15 |
5 |
300 |
|
|
300 |
1.6 |
18.5 |
6 |
500 |
|
|
400 |
2.0 |
22 |
8 |
600 |
|
|
500 |
2.4 |
30 |
10 |
800 |
|
Note: in addition to the above mentioned equipment, we also provide the design for the entire production line and auxiliary equipment election. We will send technical engineer to the buyer’s site for installation and debugging machine until the quality gypsum is produced.
