Specifications
Hydraulic oil pess machinery includes three parts:main engine,hydraulic system and electronic system.We have 3 models for you.Hydraulic oil press specific introduction:
1. Main engine
Main engine includes base, upright, top plate, oil drip pan nut and so on , it is one of the main parts. Firstly the oil material is put into the assembly of the press boring , then it being droved up by the oil cylinder piston ,oil will outflow from the gap of press boring ,and then pass the oil drip pan to the drum for oil storage.
2. Hydraulic system
Hydraulic system is the main power force of this machine, it includes transmission shaft, turbine, worm gear, gear pump, high pressure pump, overflow valve; super high pressure safety valve; hand-operated valve; seamless steel tube; pipeline connect and other spare parts. This machine adopts the advanced power pack of the world, and compared with two plunger pump, it is faster , higher pressure and can resist higher temperature, it can continue working when the oil temperature is above 65 but needn’t cooling unit.
3. Electronic system
Electronic system is the most advanced part of this machine, it is fully automatic, easy to operate, and it needs no special request to the operator, so this machine is particularly suitable for peasant.
This machine is composed of motor, volt meter, pressure gauge, power insurance and so on.
Hydraulic oil press capacity
materials |
models |
time period/time |
weight/time |
output /10 hour |
oil ratio |
|
sesame |
type 180 |
5-8 minutes |
1-3kg |
150-300kg |
42%--52% |
type 230 |
4-6minutes |
2-7.5kg |
450-750kg |
||
type 320 |
8-10minutes |
5-15kg |
800-1200kg |
||
|
almond |
type 180 |
5-8 minutes |
1-2.5kg |
150-250kg |
40%-45% |
type 230 |
4-6minutes |
2-6kg |
350-500kg |
||
type 320 |
8-10minutes |
5-14kg |
700-1000kg |
||
|
walnut meat
|
type 180 |
5-8 minutes |
1-2.5kg |
150-250kg |
50%-60% |
type 230 |
4-6minutes |
2-6kg |
350-500kg |
||
type 320 |
8-10minutes |
5-14kg |
700-1000kg |
||
|
pine nut |
type 180 |
5-8 minutes |
1-2.5kg |
150-250kg |
45%-60% |
type 230 |
4-6minutes |
2-7kg |
350-500kg |
||
type 320 |
8-10minutes |
5-14kg |
700-1000kg |
