Quilting Machine Easy To operation
1. Machine Introduction:
1), machine covers an area of only 3/5 other quilting machine.
2), synchronous belt transmission, quilting high precision, low noise.
3), bolt detection device, wire automatic stop, convenient threading.
4), computer, electrical have abnormal phenomenon such as the machine will automatically stop working, and at the same time showing failure.
5), figure using DST play version of the system, the computer in the existing more than four hundred sewing pattern.
The machine features:
1), the computer Chinese layout, easy to operate.
2), the size of the quilting, injection speed, add such as design of adjustable needle spacing.
3), automatic memory return, repair, and other functions.
4), computer screen color display working status, accumulated output, low power consumption.
5), the machine can be customized according to user needs all kinds of size.
2.machine advantages:
1). Reliable industrial control system, main shaft adopts variable frequency drive system, X and Y to use stepping driving system;
2). With synchronized browsing functions, can automatically identify a variety of formats, designs and graphic designs for rotation and mirror;
3). Computer all Chinese layout, operation simple and convenient;
4). The quilting size, injection speed, stitch, pattern and so on arbitrary adjustable;
5). Quilted pattern can press, needs to be increased at the needle point, back to the arbitrary adjustable needle way;
6). Use wire automatic detection, automatic return of memory, auto repair, and other functions;
7). The computer screen color display working status, can automatic cumulative production, etc.The main control components adopt imported electrical appliances, synchronous belt transmission, quilting precision is higher.
8). Can be customized according to user needs different sizes
9). The system test function, can quickly detect the working state of the machine, used for maintenance;
10). Through boundaries and edge empty set pattern, the pattern graphics can automatically zoom;
11). The nose offers dynamic pressure foot and fixed presser foot two sets of devices, and easy to change.
12). Using the latest silent process, motor and computer quilting machine use voice dropped to a certain level, suitable for large and medium-sized cities to the requirement of commercial noise!
3.Technical parameters:
|
|
|
|
|
model number |
HTO-HFJ-5-2023 |
HTO-HFJ-5-2225 |
HTO-HFJ-5-2528 |
HTO-HFJ-5-3032 |
pack by size |
2M*2.3M |
2.2M*2.5M |
2.5M*2.5M |
3M*3.2M |
falling needle size |
1.8M*2.1M |
2M-2.3M |
2.3M*2.6M |
2.8M*3M |
machine head |
Single head, single needle, double lock type line mark, big hook |
|
||
sewing thickness |
1200g/ m*2 |
|
|
|
sewing speed |
2000needle/m needle pitch 2-7mm |
|
|
|
needle |
MR5 18-22# |
|
|
|
machine size |
3.0m*2.9m*1.4m |
3.2m*3.1m*1.4m |
3.5m*3.4m*1.4m |
4.0m*3.5m*1.4m |
power |
220v 1.5KW |
|
|
|
weight |
600KG |
700KG |
800KG |
1000KG |
package size |
3.2m*1.2m*1m |
3.4m*1.2m*1m |
3.6m*1.2m*1m |
4.2m*1.2m*1m |
4.Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
