Professional Fabric Inspection And Rolling Machine
1.Machine introduction
USES:
1, mainly used for cotton, hemp, knitted and woven cloth, color difference, stain test as well as the length, drum, loose fabric.And it is the ideal necessary products for textile and apparel industry .
Advantages:
a. equipped with frequency converter speed control device, which can realize 0-60 m/MIN stepless speed regulation.
b. tensioning device, make the elastic cloth can be arbitrary regulation.
c. advanced digital display meter long, display clear and accurate, and has the metric system and code switching function.
d. Castor with direction, mobile convenience.
e. equipped with photoelectric neat edge devices, mobile car cloth, which has the ability of automatic edge features.
f. which can realize four big functions including the cloth to cloth, cloth to batching, roll to roll, batching to Piece Fabric .
g. equipped with synchronized feed device for inspection by the cloth completely without tension, to ensure that the fabric deformation and stretch, is currently the most advanced domestic import substitution.Especially the most applicable to amine nylon material and underwear manufacturers.
2.Technical parameters
Model | HTO-YBJ4 |
voltage | 380v |
Power | 1.5kw |
Capacity | 300-500/h |
Fabric Diameter | 580MM |
Fabric width | 1800-2400MM |
Edge-aligning error | 5MM |
Inspecting Speed | 0-60M/min |
Cloth inspection way | cloth to cloth, cloth to batching, roll to roll, batching to Piece Fabric |
Length error | 0.3% |
Machine size | 2700-3300mm*1550*1950mm
|
Weight | 900-1000KG |
Size(L*W*H) | 930*480*1110mm |
3.Contact information
If you need further information, please contact us freely, we will do our best to cooperate with you.
